Sunicorn HP Series

深圳市尚科新能源有限公司
类型: 离网
功率范围: 1~5 kW
地区: 中国大陆 中国大陆
注意: 您的询盘将直接发送至深圳市尚科新能源有限公司

描述:

1. Rated power 1KW to 5KW
2. PWM solar charge controller
3. Power factor 1
4. Pure sine wave AC output
5. Overload, short circuit and deep discharge protection
6. Configurable AC/ solar input priority via LCD setting
7. Compatible to mains voltage or generator power
8. WIFI/ GPRS remote monitoring (optional)
9. Parallel operation for Sunicorn HP 4KW/5KW

产品特点

产品型号
Sunicorn-HP 1KVA Sunicorn-HP 2KVA Sunicorn-HP 3KVA
输入参数(直流)
最大输入功率
0.9 kW 1.8 kW 1.8 kW
输出参数(交流)
最大输出功率
1 kW 2 kW 3 kW
交流电压范围
219~241.5 V 219~241.5 V 219~241.5 V
标称交流电压
230 V 230 V 230 V
频率
50, 60 Hz 50, 60 Hz 50, 60 Hz
功率因数 (cosθ)
1 1 1
相数
1 1 1
一般参数
尺寸(高/宽/厚)
316x240x95 mm 355x272x100 mm 385x272x100 mm
重量
5 kg 6.4 kg 7.5 kg
环境温度范围 -0 ~ +55 ℃
相对湿度 5-95 %
通讯接口 RS 232, WLAN
显示屏 LCD
防护性能
防护性能 短路保护,过载保护,过压保护,过流保护,过热保护,漏电保护设备(RCD),极性反接保护,浪涌保护

Sunicorn HP series off grid solar inverter is integrated with a PWM solar charge controller, a high frequency pure sine wave inverter and a UPS function module in one machine, which is perfect for off grid backup power and self-consumption applications. Sunicorn series inverter is available for motoring access. Customer can monitor the PV system on web or cellphone anytime anywhere.


Features:

● Rated power 1KW to 5KW, power factor 1

● PWM solar charge controller

● High frequency inverter with small size and light weight

● Pure sine wave AC output

● Overload, short circuit and deep discharge protection

● Configurable AC/ solar input priority via LCD setting

● Compatible to mains voltage or generator power

● WIFI/ GPRS remote monitoring (optional)

● Parallel operation for Sunicorn HP 4KW/5KW


Product Overview:

System Connection:
Parallel Connection:
Product Processing:

About us
Shenzhen Sacolar New Energy Co., Ltd., a wholly owned subsidiary of Growatt, is a professional solar inverter manufacture.
With the assembly of the top talents in the industry, Sacolar is dedicated to solar power product design,development and production. Relying on the existing network technology, company perfectly combines the solar power products and the Internet. Even in remote areas, we can manage to monitor the status of our off-grid PV systems anytime, anywhere.

Our main products include:
● Off grid solar inverter
● Modified sine wave inverter
● On/off grid hybrid inverter
● On grid solar inverter
● MPPT solar charge controller
● Solar pump inverter
● UPS
