Roof-Ground Solar Mount

Installation Scenarios: Office buildings, malls, factories, residential complexes, solar farms with parking.

• Waterproof design for rainwater management and long-term durability

• EV-ready – compatible with electric vehicle charging stations

• Customizable span & size to suit residential, commercial, or industrial parking areas

• Material: Corrosion-resistant structure with anodized aluminum or galvanized steel

• Options: Single post / Double post

PV Design and Case Studies

Installation Scenarios: Utility-scale projects, farmland integration, open landscapes, desert or hilly terrain

• Tilt: Adjustable to site-specific latitude

• Strong wind & snow resistance for diverse environments

• Modular design for easy expansion

• Fast on-site installation with pre-assembled components

• Foundation: Concrete or ground screw

PV Design and Case Studies

Installation Scenarios: Utility-scale PV plants, large commercial installations in high-irradiation zones

• Type: Single-axis solar tracking

• Increases power generation by 20–30%

• Smart tracking algorithms for optimal sun exposure

• Durable drive system with minimal maintenance

PV Design and Case Studies

Installation Scenarios: Residential rooftops, villas, heritage buildings

Components: Stainless steel tile hooks, aluminum rails

Compatible with all tile types – flat, curved, slate, Roman

No roof damage – tile hooks secure under tiles without penetration

Flexible rail system allows for quick module alignment

PV Design and Case Studies

Installation Scenarios: Factories, warehouses, commercial buildings, barns

• Types: Standing seam clamps, trapezoidal/corrugated sheet solutions

• Non-penetrating options preserve roof integrity

• Lightweight, yet robust structure

• Fast installation with clamp-on and rivet solutions

PV Design and Case Studies

Installation Scenarios: Office buildings, schools, hospitals, flat-roof commercial facilities

Types: Ballasted or fixed tilt

No roof penetration with ballast options

Lightweight design to reduce load stress

Wind deflectors available for high-wind regions

PV Design and Case Studies

Installation Scenarios: Lakes, reservoirs, irrigation ponds, fish farms

UV-resistant and corrosion-proof HDPE or composite floats

Designed for stability on water surfaces

Dual-use for aquaculture & energy (agri-aqua PV)

PV Design and Case Studies

Range Includes: Mid clamps, end clamps, rails, hooks, bolts, grounding lugs, splices

Universal compatibility with major module sizes (e.g., 30mm, 35mm frames)

Corrosion-proof materials like aluminum & stainless steel

Complete accessory kits for installers and distributors

Use Cases: Spare parts supply, OEM, project customization
