类型: | 单晶硅 |
---|---|
功率范围: | 250 ~ 275 Wp |
地区: |
中国大陆
![]() |
产品型号 |
|
||||||
---|---|---|---|---|---|---|---|
质量保证 | |||||||
产品质量保证 | 10 年 | ||||||
功率输出保证 | 10年期90%输出功率保证,25年期80%输出功率保证 | ||||||
电性能参数(STC) | |||||||
峰值功率 (Pmax) |
|
||||||
峰值工作电压(Vmpp) |
|
||||||
峰值工作电流(Impp) |
|
||||||
开路电压(Voc) |
|
||||||
短路电流(Isc) |
|
||||||
组件效率 |
|
||||||
功率偏差(正) |
|
||||||
标准测试条件(STC):太阳能辐射通量1000W/m2,大气参数1.5,组件温度25℃。 | |||||||
电性能参数(NOCT) | |||||||
峰值功率 (Pmax) |
|
||||||
峰值工作电压(Vmpp) |
|
||||||
峰值工作电流(Impp) |
|
||||||
开路电压(Voc) |
|
||||||
短路电流(Isc) |
|
||||||
最大耐久温度 |
|
||||||
电池片标称工作温度(NOCT):太阳能辐射通量800W/m2,大气参数1.5,环境温度20℃,风速1 m/s。 | |||||||
温度特性 | |||||||
工作温度 | -40~85 °C | ||||||
温度系数(Pmax) | -0.39 %/°C | ||||||
温度系数(Voc) | -0.32 %/°C | ||||||
温度系数(Isc) | 0.05 %/°C | ||||||
系统集成参数 | |||||||
最大系统电压 | 1000 V | ||||||
最大反向电流 | 15 A | ||||||
保险丝额定电流 | 15 A | ||||||
物理参数 | |||||||
组件尺寸(高/宽/厚) | 1640x992x40 mm | ||||||
重量 | 19 kg | ||||||
电池片类型 | 单晶硅 | ||||||
电池片规格 | 156×156 mm | ||||||
电池片数量 | 60 | ||||||
玻璃类型 | 钢化 | ||||||
玻璃厚度 | 3.2 mm | ||||||
边框类型 | 阳极氧化铝合金 | ||||||
旁路二极管数 | 6 | ||||||
接线盒防护等级 | IP 67 | ||||||
连接器类型 | MC4 | ||||||
电缆截面 | 4 mm2 | ||||||
电缆长度 | 900 mm | ||||||
认证 |
|
||||||
下载公司产品详情 |
RS6C-M
High module conversion efflciency (up to 15.2%), through superior manufacturing technology
Guaranteed 0-5W positive power output tolerance
Anti-reflective,hydrophobic coating improves light absorption and reduces surface dust
Excellent performance under low light environments (mornings,evenings and cloudy days)
Entire module certifled to withstand high wind loads ensures high rel iability (2400 Pascal) and snow loads (5400 Pascal)
RS5A-M
High module conversion efflciency (up to 15.26%), through superior manufacturing technology
Guaranteed 0-5Wpositive power output tolerance
Anti-reflective,hydrophobic coating improves light absorption and reduces surface dust
Excellent performance under low light environments (mornings,evenings and cloudy days)
Entire module certifled to withstand high wind loads (2400 Pascal) and snow loads (5400 Pascal)
RS6S-P
High module conversion efflciency (up to 15.2%), through superior manufacturing technology
Guaranteed 0-5W positive power output tolerance ensures high reliability
Anti-reflective,hydrophobic coating improves light absorption and reduces surface dust
Excellent performance under low light environments (mornings,evenings and cloudy days)
Entire module certifled to withstand high wind loads (2400 Pascal) and snow loads (5400 Pascal)
