WT 260P17

Wattrom
价 格:
起价 ¥3.01 / Wp *
类型: 多晶硅
功率范围: 264.99 Wp
地区: 罗马尼亚 罗马尼亚
注意: 您的询盘将直接发送至Wattrom

描述:

1. Competitive price.
2. Guaranteed +1.6% positive power tolerance.
3. 5 years product warranty and 25 year power warranty.
4. Robust frame to up to 5400 Pa load.
5. Excellent performance under low light environment.
6. International certificates to ensure the best quality and performance.
7. Enhanced design for easy installation and long term reliability.

产品特点

产品型号
WT 260P17
质量保证
产品质量保证 10 年
功率输出保证 12年期90%输出功率保证,25年期80%输出功率保证
电性能参数(STC)
峰值功率 (Pmax)
264.99 Wp
峰值工作电压(Vmpp)
32.04 V
峰值工作电流(Impp)
8.466 A
开路电压(Voc)
38.28 V
短路电流(Isc)
9.002 A
组件效率
16.76 %
功率偏差(正)
+ 1.6 %
  标准测试条件(STC):太阳能辐射通量1000W/m2,大气参数1.5,组件温度25℃。
电性能参数(NOCT)
峰值功率 (Pmax)
204.15 Wp
峰值工作电压(Vmpp)
30.12 V
峰值工作电流(Impp)
6.776 A
开路电压(Voc)
35.99 V
短路电流(Isc)
7.204 A
最大耐久温度
45±2 °C
  电池片标称工作温度(NOCT):太阳能辐射通量800W/m2,大气参数1.5,环境温度20℃,风速1 m/s。
温度特性
工作温度 -40~85 °C
温度系数(Pmax) -0.397 %/°C
温度系数(Voc) -0.3166 %/°C
温度系数(Isc) 0.0473 %/°C
系统集成参数
最大系统电压 1000 V
最大反向电流 15 A
保险丝额定电流 20 A
物理参数
组件尺寸(高/宽/厚) 1657x998x38 mm
重量 18.1 kg
电池片类型 多晶硅
电池片规格 156×156 mm
电池片数量 60
玻璃类型 防反射镀膜,高透明
玻璃厚度 3.2 mm
封装材料 EVA
背板类型 PET
边框类型 阳极氧化铝合金
旁路二极管数 3
接线盒防护等级 IP 65
连接器类型 Tyco Solarlock
电缆 4 mm2
电缆长度 1000 mm
PDF
下载公司产品详情
Product Features:

WT 260P16 is a robust solar panel with 60 solar cells. This panel can be used for on/off-grid applications. Our meticulous design and the newest production technology ensure a high-yield and long term performance for every manufactured panels.

In the WT 260P16 production process, we use only TUV InterCert Saar and ISO 9001:2008 certified raw materials that guarantee the long term performance. Because we are focused on the high quality and long cycle life of WATTROM photovoltaic panels, we executed tests both of raw materials and manufactured solar modules. Our rigurous quality control realized along whole technological flow guarantees that WATTROM solar panels ensure the highest quality standards possible.

The WT 260P16 photovoltaic panel is distinguished by high efficiency of up to 16.4% and output power tolerance of 1.6%.

The WT 260P16 has ISO 9001:2008 and TUV InterCert Saar certification which provide that Wattrom photovoltaic panel meets European quality. The WT 260P16 solar panels is CE marked.

About Wattrom:

Tritech Group is a Romanian producer of high efficiency polycrystalline photovoltaic panels. In 2015, the company invested in the construction of a modern factory. Located in Ovidiu City, Constanta Country, the factory provides the strategic advantage to be situated close to the A4 highway and the Constanta harbour.

The factory is equipped with professional production machinery, that ensures the highest quality of the produced solar panels. The acquisition and use of cutting-edge production machinery is, for our clients, the best warranty that we offer high efficiency photovoltaic panels. In the production process we use an ultra modern production line and ISO 9001:2008 and TUV InterCert Saar certified raw materials, in order to obtain high performances.

Tritech Group is photovoltaic panels producer holding a control and warranty technology of the products offered to our clients. Because we are focused on the high quality and long cycle life of our products, we decided to execute tests both of raw materials and of the manufactured photovoltaic panels. The testing is performed continuously, both visually and using some complex testing systems. The quality control is executed by trained responsible quality control people. The quality control executed rigorously throughout the all technological flow ensures that the manufactured photovoltaic panels meet the highest quality standards.

The manufactured photovoltaic panels are registered and marketed under the WATTROM brand. The Wattrom photovoltaic panels are CE marked.

In every step of production process, Tritech Group verifies the quality of manufactured WATTROM photovoltaic panels. Testing efficiency is a different step with high importance. We test efficiency of every WATTROM solar panels with a complex and modern system. The complex machinery offers synthetized information about tested solar panels. The resulted dates are recorded in our database. A sticker is automatically generated, printed with the results generated from testing. The sticker confirms the performance of each manufactured solar module, being easily read and understood by everyone.

Depending on our clients' requests, we can deliver polycrystalline photovoltaic panels of different sizes and yields. Also, we offer competitive prices on the intern market, but also on the foreign market.

Tritech Group is a reliable and flexible partner, able to satisfy its clients' most demanding needs.

Wattrom

27 Poporului Street, Constanta
给该供应商发送信息
Tritech Group is a Romanian producer of high efficiency polycrystalline photovoltaic panels. In 2015, the company invested in the construction of a modern factory. Located in Ovidiu City, Constanta Country, the factory provides the strategic advantage to be situated close to the A4 highway and the Constanta harbour.

The factory is equipped with professional production machinery, that ensures the highest quality of the produced solar panels. The acquisition and use of cutting-edge production machinery is, for our clients, the best warranty that we offer high efficiency photovoltaic panels. In the production process we use an ultra modern production line and ISO 9001:2008 and TUV InterCert Saar certified raw materials, in order to obtain high performances.

Tritech Group is photovoltaic panels producer holding a control and warranty technology of the products offered to our clients. Because we are focused on the high quality and long cycle life of our products, we decided to execute tests both of raw materials and of the manufactured photovoltaic panels. The testing is performed continuously, both visually and using some complex testing systems. The quality control is executed by trained responsible quality control people. The quality control executed rigorously throughout the all technological flow ensures that the manufactured photovoltaic panels meet the highest quality standards.

The manufactured photovoltaic panels are registered and marketed under the WATTROM brand. The Wattrom photovoltaic panels are CE marked.

In every step of production process, Tritech Group verifies the quality of manufactured WATTROM photovoltaic panels. Testing efficiency is a different step with high importance. We test efficiency of every WATTROM solar panels with a complex and modern system. The complex machinery offers synthetized information about tested solar panels. The resulted dates are recorded in our database. A sticker is automatically generated, printed with the results generated from testing. The sticker confirms the performance of each manufactured solar module, being easily read and understood by everyone.

Depending on our clients' requests, we can deliver polycrystalline photovoltaic panels of different sizes and yields. Also, we offer competitive prices on the intern market, but also on the foreign market.

Tritech Group is a reliable and flexible partner, able to satisfy its clients' most demanding needs.
