RS7I-M 425-460W

瑞兴源光伏科技有限公司

电池技术：
功率范围：	425 ~ 460 Wp
地区：	中国大陆

注意： 您的询盘将直接发送至瑞兴源光伏科技有限公司。

描述：

1. 通过CE，TUV IEC61215和IEC61730，VDE，CEC认证和PID-free认可。
2. 品质稳定可靠，性价比高，由美国丘博保险集团提供保险。
3. 正公差为0-+6W。
4. 快速交付。

产品信息
公司档案页

产品特点

类型

单晶硅

产品型号

425W

430W

435W

440W

445W

450W

460W

质量保证

产品质量保证

12 年

功率输出保证

30年期84.8%输出功率保证

电性能参数（STC）

峰值功率（Pmax）

425 Wp

430 Wp

435 Wp

440 Wp

445 Wp

450 Wp

460 Wp

峰值工作电压（Vmpp）

40.5 V

40.7 V

40.9 V

41.1 V

41.3 V

41.5 V

41.9 V

峰值工作电流（Impp）

10.5 A

10.57 A

10.64 A

10.71 A

10.78 A

10.85 A

10.98 A

开路电压（Voc）

48.3 V

48.5 V

48.7 V

48.9 V

49.1 V

49.3 V

49.7 V

短路电流（Isc）

11.23 A

11.31 A

11.39 A

11.46 A

11.53 A

11.6 A

11.74 A

组件效率

19.24 %

19.46 %

19.69 %

19.91 %

20.14 %

20.37 %

20.67 %

功率偏差（正）

+ 1 %

标准测试条件（STC）：太阳能辐射通量1000W/m²，大气参数1.5，组件温度25℃。

电性能参数（NOCT）

峰值功率（Pmax）

317.4 Wp

321.1 Wp

324.9 Wp

328.6 Wp

332.3 Wp

336.1 Wp

峰值工作电压（Vmpp）

37.7 V

37.9 V

38.1 V

38.3 V

38.5 V

38.6 V

38.8 V

峰值工作电流（Impp）

8.42 A

8.47 A

8.53 A

8.59 A

8.64 A

8.7 A

8.8 A

开路电压（Voc）

45.3 V

45.5 V

45.7 V

45.8 V

46 V

46.2 V

46.6 V

短路电流（Isc）

9.08 A

9.15 A

9.21 A

9.27 A

9.33 A

9.38 A

9.4 A

最大耐久温度

45±2 °C

电池片标称工作温度（NOCT）：太阳能辐射通量800W/m²，大气参数1.5，环境温度20℃，风速1 m/s。

温度特性

工作温度

-40~85 °C

温度系数（Pmax）

-0.39 %/°C

温度系数（Voc）

-0.32 %/°C

温度系数（Isc）

0.05 %/°C

系统集成参数

最大系统电压

1500 V

保险丝额定电流

20 A

物理参数

组件尺寸（高/宽/厚）

2115x1052x30 mm

重量

23 kg

电池片规格

166×166 mm

电池片数量

144

玻璃类型

钢化

玻璃厚度

3.2 mm

边框类型

阳极氧化铝

旁路二极管数

接线盒防护等级

IP 67

连接器类型

MC4

电缆截面

4 mm²

电缆长度

300 mm

PDF

下载公司产品详情

RS7I-166MM

RS7I series redefined the high-efficiency module series by integrating 166mm silicon wafers with multi-busbar, and half-cut cell technologies.

The maximum module efficiency of the half-cell series is 20.93%, and the maximum power output of the front side is 450W. Affected by a significant increase in product power, the application of the RS7I series in large commercial and utility power stations can significantly reduce LCOE, BoS, EPC, and land costs.

GERMANY STANDARD FACTORY

Our manufacturing factory is accredited by ISO9001&ISO14001. Equipped with advanced automatic production lines, now our capacity already reach 800MW/year. Full ranges of Restar solar panels are produced in accordance with international standards of IEC 61730 and IEC 61215.

Certificationhttps://www.enf.com.cn/pv/panel-datasheet/crystalline/45607

Global Logistics Advantage

Global warehouse : To expand quick logistic, Resun built warehouse and shop in Euro- Poland, Netherland, Middle East- Dubai, Africa- Nigeria, Uganda, Latin America- Brazil, Chile, Colombia, the local team offer 7/24 service and technical backup for your solar projects.
