HW-P372H 330-350

HW-P372H 330-350

Hiwatt Solar Limited
价 格:
起价 ¥1.76 / Wp *
类型: 多晶硅
功率范围: 330 ~ 350 Wp
地区: 中国大陆 中国大陆
注意: 您的询盘将直接发送至Hiwatt Solar Limited

替代产品

SF-M18/144 570-580W

浙江旭发新能源有限公司
起价 ¥1.97 / Wp *
  • 电池片类型: 单晶硅
  • 组件尺寸: 2278x1134x35 mm
  • 重量: 28 kg
  • 电池片规格: 182x182 mm
  • 玻璃厚度: 3.2 mm
  • 峰值功率: 570 Wp
  • 峰值电压: 43.45 V
  • 峰值电流: 13.12 A
  • 开路电压: 51.3 V
  • 短路电流: 13.86 A
  • 效率: 22.07 %
  • 产品质量保证: 15 年
  • 功率输出保证: 10年期93.1%输出功率保证,30年期80%输出功率保证

产品特点

产品型号
330 335 340 345 350
质量保证
产品质量保证 12 年
功率输出保证 25年期84.8%输出功率保证
电性能参数(STC)
峰值功率 (Pmax)
330 Wp 335 Wp 340 Wp 345 Wp 350 Wp
峰值工作电压(Vmpp)
37.4 V 37.56 V 37.74 V 37.92 V 38.1 V
峰值工作电流(Impp)
8.85 A 8.92 A 9.01 A 9.1 A 9.19 A
开路电压(Voc)
45.97 V 46.17 V 46.37 V 46.57 V 46.77 V
短路电流(Isc)
9.35 A 9.45 A 9.55 A 9.65 A 9.75 A
组件效率
16.7 % 17 % 17.2 % 17.5 % 17.8 %
功率偏差(正)
+ 1.5 % + 1.5 % + 1.5 % + 1.5 % + 1.5 %
  标准测试条件(STC):太阳能辐射通量1000W/m2,大气参数1.5,组件温度25℃。
电性能参数(NOCT)
峰值功率 (Pmax)
245 Wp 249 Wp 253 Wp 256 Wp 260 Wp
峰值工作电压(Vmpp)
34.69 V 34.94 V 35.11 V 35.27 V 35.43 V
峰值工作电流(Impp)
7.08 A 7.14 A 7.21 A 7.28 A 7.35 A
开路电压(Voc)
43.11 V 43.3 V 43.49 V 43.67 V 43.86 V
短路电流(Isc)
7.54 A 7.62 A 7.7 A 7.79 A 7.87 A
最大耐久温度 43±2 °C
  电池片标称工作温度(NOCT):太阳能辐射通量800W/m2,大气参数1.5,环境温度20℃,风速1 m/s。
温度特性
工作温度 -40~85 °C
温度系数(Pmax) -0.34 %/°C
温度系数(Voc) -0.25 %/°C
温度系数(Isc) 0.04 %/°C
系统集成参数
最大系统电压 1500 V
保险丝额定电流 30 A
物理参数
组件尺寸(高/宽/厚) 1979x996x35 mm
重量 21.5 kg
电池片类型 多晶硅
电池片数量 72
旁路二极管数 3
接线盒防护等级 IP 68
电缆截面 4 mm2
PDF
下载公司产品详情

Hiwatt Solar Limited

Click to show company phone
www.hiwattsolar.com
中国大陆
No.6, Fazhan Road, Dongtai, Jiangsu
员工数: 200
注意: 您的询盘将直接发送至Hiwatt Solar Limited

晶体硅

产量 (MW)/: MWp
单晶硅,多晶硅
功 率 范 围(Wp): 275-670

有用联系人

Contact Face
Mr.liam
公司描述

Hiwatt Solar is a technology company specializing in the research , development, production and sales of solar photovoltaic modules. Hiwatt Solar is a world leading solar module manufacturer and comprehensive solar solution provider.Our solar modules production capacity reaches 2.2GW . We have our own fully automated production line which ensures the quality is strict and stable.we can produce market mainstream solar modules ,including large size 210mm cell solar module power up to 670W plus, MBB, high efficient single glass and double glass bifacial modules, both mono and poly, full cells and half cut cells solar modules.

We are committed to the development and application of new photovoltaic modules, dedicated to provide customers with high quality photovoltaic products, also provide fast and efficient quality service.Hiwatt Solar has a variety of products, and our PV products have been tested and recognized by many international authorities.

Hiwatt Solar is always focusing on the quality as the pillar of growth of the company. We have established a comprehensive range of tests and controls before, during and after the production, following the guidelines of IEC 61215 & IEC 61730 requirements. From the selection of raw materials to the assembly of finished products and systems, the company implements strict management and quality system to ensure the high-quality performance of each module and system.

Hiwatt Solar PV products have highly recognized by clients from Japan, Vietnam, Turkey, Myanmar, Sri Lanka, Saudi Arabia, Germany, Italy, Switzerland, Spain, Bulgaria, Greece, Norway ,Denmark,Estonia,Latvia, Lithuania,Russia,Czech,Slovakia,Austria,Netherlands,Ukraine, Sweden, Finland, Poland, Portugal, Macedonia,Slovenia,Australia, Kenya, Uganda, Tunisia, Morocco, Brazil, Chile, Argentina and many other counties and regions.

Our vision is to provide the most compelling value to our customers through sustainable and innovative solutions. Continuously invest in research and development and expand our PV products portfolio to meet the evolving needs of the world.
