JD535-560-DE21M(18)

常州极地太阳能电力有限公司

类型：	单晶硅
功率范围：	535 ~ 560 Wp
地区：	中国大陆

注意： 您的询盘将直接发送至常州极地太阳能电力有限公司。

描述：

产品信息
公司档案页

产品特点

产品型号

535

540

545

550

555

560

质量保证

产品质量保证

10 年

功率输出保证

10年期92.1%输出功率保证，25年期83.1%输出功率保证

电性能参数（STC）

峰值功率（Pmax）

535 Wp

540 Wp

545 Wp

550 Wp

555 Wp

560 Wp

峰值工作电压（Vmpp）

31.2 V

31.4 V

31.6 V

31.8 V

32 V

32.2 V

峰值工作电流（Impp）

17.15 A

17.2 A

17.25 A

17.3 A

17.34 A

17.39 A

开路电压（Voc）

37.6 V

37.8 V

38 V

38.2 V

38.4 V

38.6 V

短路电流（Isc）

18.16 A

18.21 A

18.26 A

18.31 A

18.35 A

18.4 A

组件效率

20.5 %

20.7 %

20.9 %

21 %

21.2 %

21.4 %

功率偏差（正）

+ 1 %

标准测试条件（STC）：太阳能辐射通量1000W/m²，大气参数1.5，组件温度25℃。

电性能参数（NOCT）

峰值功率（Pmax）

400 Wp

404 Wp

408 Wp

412 Wp

416 Wp

420 Wp

峰值工作电压（Vmpp）

29 V

29.2 V

29.4 V

29.6 V

29.8 V

30 V

峰值工作电流（Impp）

13.79 A

13.84 A

13.88 A

13.92 A

13.96 A

14 A

开路电压（Voc）

35.2 V

35.4 V

35.6 V

35.8 V

36 V

36.2 V

短路电流（Isc）

14.74 A

14.79 A

14.83 A

14.87 A

14.91 A

14.95 A

最大耐久温度

44±2 °C

电池片标称工作温度（NOCT）：太阳能辐射通量800W/m²，大气参数1.5，环境温度20℃，风速1 m/s。

温度特性

工作温度

40~85 °C

温度系数（Pmax）

0.39 %/°C

温度系数（Voc）

0.3 %/°C

温度系数（Isc）

0.05 %/°C

系统集成参数

最大系统电压

1500 V

保险丝额定电流

30 A

物理参数

组件尺寸（高/宽/厚）

2384x1096x35 mm

重量

28 kg

电池片类型

单晶硅

电池片数量

110

玻璃类型

钢化

玻璃厚度

3.2 mm

边框类型

阳极氧化铝合金

旁路二极管数

接线盒防护等级

IP 68

电缆截面

4 mm²

电缆长度

300 mm
