P156-C

P156-C

上海超日太阳能科技股份有限公司
电池片类型: 多晶硅
功率范围: 3.7668~4.2202 Wp
地区: 中国大陆 中国大陆

替代产品

M182B10B

无锡施莱德新能源有限公司
起价 ¥0.326 / Wp *
  • 峰值功率: 7.66 W
  • 电池片类型: 双面
  • 尺寸: 182x182 mm
  • 对角线: 247±0.5 mm
  • 电池片厚度: 170 µm

产品特点

产品型号
P156-C 3.7668 P156-C 3.8186 P156-C 3.8785 P156-C 3.9355 P156-C 3.9954 P156-C 4.0557 P156-C 4.1148 P156-C 4.1688 P156-C 4.2202
产品特点
电池片技术 多晶硅
尺寸 156×156 mm
对角线 220±1 mm
电池片厚度 200 ± 20 µm
正面 (-)
栅线数 2
栅线宽度 1.5 mm
栅线材料
减反射膜 氮化硅
背面 (+)
焊垫数 2
焊垫宽 4 mm
焊垫材料
背面电场 (BSF)
电性能参数(STC)
峰值功率 (Pmax)
3.7668 W 3.8186 W 3.8785 W 3.9355 W 3.9954 W 4.0557 W 4.1148 W 4.1688 W 4.2202 W
峰值工作电压 (Vmpp)
0.5007 V 0.5029 V 0.5053 V 0.5079 V 0.5108 V 0.5147 V 0.5185 V 0.5219 V 0.5251 V
峰值工作电流 (Impp)
7.5239 A 7.5936 A 7.6762 A 7.75 A 7.8227 A 7.8811 A 7.9367 A 7.9889 A 8.0368 A
开路电压 (Voc)
0.6048 V 0.6068 V 0.6096 V 0.6124 V 0.6155 V 0.6192 V 0.6224 V 0.6252 V 0.6277 V
短路电流 (Isc)
8.0614 A 8.122 A 8.2006 A 8.27 A 8.3426 A 8.4008 A 8.458 A 8.5061 A 8.5559 A
电池片效率
15.35-15.5 % 15.5-15.75 % 15.75-16 % 16-16.25 % 16.25-16.5 % 16.5-16.75 % 16.75-17 % 17-17.25 % 17.25-17.5 %
填充因子 (FF)
77.2757 % 77.4907 % 77.5919 % 77.708 % 77.8142 % 77.9692 % 78.1681 % 78.3856 % 78.5764 %
