LNE-N10

苏州潞能能源科技有限公司

电池片类型：	TOPCon
功率范围：	7.86~8.29 Wp
地区：	中国大陆

联系生产商

注意： 您的询盘将直接发送至苏州潞能能源科技有限公司。

描述：

产品信息
公司档案页

产品特点

产品型号

7.86

7.89

7.96

7.92

7.99

8.02

8.06

8.09

8.12

8.16

8.19

8.22

8.25

8.29

产品特点

电池片技术

TOPCon

尺寸

182x182 mm

对角线

247±0.25 mm

电池片厚度

140 ± 14 µm

正面 (-)

栅线宽度

0.036±0.02 mm

背面 (+)

焊垫宽

0.036±0.02 mm

背面电场 (BSF)

铝

电性能参数（STC）

峰值功率 (Pmax)

7.86 W

7.89 W

7.9 W

7.92 W

7.99 W

8.02 W

8.06 W

8.09 W

8.12 W

8.16 W

8.19 W

8.22 W

8.25 W

8.29 W

峰值工作电压 (Vmpp)

0.6024 V

0.6032 V

0.6054 V

0.604 V

0.6059 V

0.6065 V

0.6073 V

0.6081 V

0.6089 V

0.6097 V

0.6106 V

0.6114 V

0.6122 V

0.6131 V

峰值工作电流 (Impp)

13.055 A

13.08 A

13.155 A

13.115 A

13.195 A

13.23 A

13.265 A

13.3 A

13.335 A

13.37 A

13.405 A

13.44 A

13.475 A

13.518 A

开路电压 (Voc)

0.7034 V

0.7042 V

0.7064 V

0.705 V

0.7069 V

0.7075 V

0.7083 V

0.7091 V

0.7099 V

0.7107 V

0.7116 V

0.7124 V

0.7132 V

0.7141 V

短路电流 (Isc)

13.615 A

13.64 A

13.715 A

13.675 A

13.755 A

13.79 A

13.825 A

13.86 A

13.895 A

13.93 A

13.965 A

14 A

14.035 A

14.078 A

电池片效率

23.8 %

23.9 %

24.1 %

24 %

24.2 %

24.3 %

24.4 %

24.5 %

24.6 %

24.7 %

24.8 %

24.9 %

25 %

25.1 %

填充因子 (FF)

82.07 %

82.14 %

82.16 %

82.15 %

82.17 %

82.2 %

82.32 %

82.42 %

82.46 %

温度特性

温度系数（Pmax）

-0.32 %/˚C

温度系数（Voc）

-0.25 %/˚C

温度系数（Isc）

0.045 %/˚C

PDF

下载公司产品详情

Dimension 182mmx182mm±0.25mm，Φ247mm±0.25mm

Cell Thickness 140±14μm

Front side (−)

SiNx AR Coating. The width of the busbar is 0.036±0.02mm

The head of the busbar is forked.

The number of the finger is 132.

The front side of the solar cell is designed as a half sheet.

Back side (+)

SiNx AR Coating. The width and length of the Ag electrode are 0.036±0.02mm.

The number of aluminium busbars is 16.

The number of the aluminum finger is 146.

Solderability（Peel strength）≥0.5N/mmResults may vary depending on the conditions.

LNE Energy — One-stop Solution for Green Energy

Persistent product quality and trustworthy and reliable supply credit have helped the company win acknowledgement from both domestic and international customers.

Our products are sold throughout Europe, America, and Southeast Asia. For the domestic market, our worldwide sales network will definitely facilitate the company's fast-track to professionalized, large-scale development. We are looking forward to creating a better future with you.

Intelligent Manufacturing

LNE Energy always insists on long-term value for clients by offering reliable products. Every incoming raw material is strictly tested before coming online to prevent any defect. LNE Energy's smart full-automation factory can carry out stable and efficient manufacturing procedures.

Quality Assurance

LNE Energy's product design and manufacturing are based on years of process and material product warranty, years of production line warranty, and a glass production line guarantee.

LNE Energy goes above and beyond in the manufacturing process, conducting double the number of tests compared to the industry average. This rigorous testing is designed to prevent micro-cracks in each panel, ensuring our products' utmost reliability.

Each panel undergoes a thorough examination by machines and QC engineers before proceeding to the subsequent steps.
