太阳能贸易平台及太阳能企业名录
  1. 电池片名录
  2. PERC 182mm 10BB
PERC 182mm 10BB

PERC 182mm 10BB

TN Solar
价 格：
起价 ¥0.267 / Wp *
电池片类型： 背钝化 (PERC)
功率范围： 7.36~7.69 Wp
地区： 中国大陆 中国大陆
联系生产商
注意： 您的询盘将直接发送至TN Solar。

描述：

  • HJT 2.0 Technology

  • -0.26%/°C Pmax temperature coefficient

  • SMBB design with Half-Cut Technology

  • Up to 90% Bifaciality

  • Sealing with PIB-based sealant

产品特点

产品型号
7.36 7.43 7.49 7.56 7.63 7.69
产品特点
电池片技术 背钝化 (PERC)
尺寸 182x182 mm
对角线 180±0.25 mm
电池片厚度 180 ± 20 µm
正面 (-)
栅线数 10
减反射膜 氮化硅
背面 (+)
焊垫数 10
电性能参数（STC）
峰值功率 (Pmax)
7.36 W 7.43 W 7.49 W 7.56 W 7.63 W 7.69 W
峰值工作电压 (Vmpp)
0.605 V 0.607 V 0.608 V 0.61 V 0.611 V 0.613 V
峰值工作电流 (Impp)
12.174 A 12.245 A 12.324 A 12.401 A 12.495 A 12.539 A
开路电压 (Voc)
0.685 V 0.685 V 0.686 V 0.687 V 0.699 V 0.69 V
短路电流 (Isc)
13.358 A 13.397 A 13.419 A 13.479 A 13.551 A 13.583 A
电池片效率
22.3 % 22.5 % 22.7 % 22.9 % 23.1 % 23.3 %
填充因子 (FF)
80.49 % 80.99 % 81.4 % 81.69 % 80.6 % 82.01 %
温度特性
温度系数（Pmax） -0.39 %/˚C
温度系数（Voc） -0.3 %/˚C
温度系数（Isc） 0.06 %/˚C
PDF
下载公司产品详情

  • HJT 2.0 Technology

Combining the gettering process and single-side μc-Si technology to ensure higher cell efficiency and higher module power.

  • -0.26%/°C Pmax temperature coefficient

More stable power generation performance and is even better in hot climates.

  • SMBB design with Half-Cut Technology

Shorter current transmission distance, less resistive loss, and higher cell efficiency.

  • Up to 90% Bifaciality

Natural symmetrical bifacial structure brings more energy yield from the backside.

  • Sealing with PIB-based sealant

Stronger water resistance, and greater air impermeability to extend module lifespan.

TN Solar —— Brighten up Your Life with Our Incredible PV Modules

Production Base

Our modules are so efficient that they make the sun jealous.

Our modules are as sleek as a stealthy ninja. With their all-black design, they'll seamlessly blend into your roof.

When you choose TN Solar, you're not just getting top-notch modules, you're also getting exceptional customer service. Our team of solar superheroes is here to guide you through every step of the process, from installation to maintenance.

Certifications

TN Solar

Click to show company phone
www.tn-solar.com
中国大陆
Wenya Road,Qianhuang Town Wujin District 213000 Changzhou City
员工数： 300
联系生产商
注意： 您的询盘将直接发送至TN Solar。

有用联系人

公司描述

TN Solar is an enterprise specialized in the integrated photovoltaic products, such as solar panels and solar cells .

  • We are specializing in making 20~200W small-size panels.

  • Our core products include PERC, TOPCON, HJT, baficial 400W-750w, world cheapest, A grade, high efficiency, up to 20bb solar cells.

  • We also offer a comprehensive warranty and after-sales service to ensure that our customers are fully satisfied with their purchase.

  • We are also committed to providing our customers with fast delivery, excellent customer service and quality assurance.We highly value our customers and provide them with unbeatable customer service as well as unbeatable prices.

Our Capacity is :

  • 5 lines for solar cells, 250,000 pcs/day.

  • 5 lines for solar panels, one 40 ft container/day.

Certificates

  • IEC61215 & IEC61730

  • fire rating Class A
