N-Type 182.2x182.2mm

G-STAR Pte. Ltd.
填充因子
填充因子
82.04 - 84.66 %
电池片效率
电池片效率
24.5 - 25.6 %
电 池 技 术
技术
TOPCon
功率范围
功率范围
8.09 - 8.45 Wp
地区
地区
新加坡 新加坡
组件尺寸
尺寸
182x182 mm
电池片厚度
电池片厚度
130 ± 13 µm
栅线数
栅线数
16
栅线宽度
栅线宽度
0.036±0.02 mm
焊垫数
焊垫数
16
焊垫宽
焊垫宽
0.03±0.02 mm
焊垫材料
焊垫材料
联系生产商
注意: 您的询盘将直接发送至G-STAR Pte. Ltd.

High Photoelectric, Conversion EfficiencyExcellent

Resistance to Hidden Cracks

Automated & intelligent production lines for quality and on-time delivery

Full-process traceability

产品特点

产品型号
8.09 8.12 8.15 8.19 8.22 8.25 8.29 8.32 8.35 8.39 8.42 8.45
电池片技术 TOPCon
尺寸 182x182 mm
对角线 247±0.25 mm
电池片厚度 130 ± 13 µm

栅线数 16
栅线宽度 0.036±0.02 mm
栅线材料

焊垫数 16
焊垫宽 0.03±0.02 mm
焊垫材料

峰值功率 (Pmax)
8.09 W 8.12 W 8.15 W 8.19 W 8.22 W 8.25 W 8.29 W 8.32 W 8.35 W 8.39 W 8.42 W 8.45 W
峰值工作电压 (Vmpp)
0.61 V 0.611 V 0.613 V 0.614 V 0.615 V 0.617 V 0.618 V 0.62 V 0.621 V 0.622 V 0.624 V 0.625 V
峰值工作电流 (Impp)
13.26 A 13.292 A 13.303 A 13.335 A 13.367 A 13.377 A 13.409 A 13.419 A 13.45 A 13.482 A 13.491 A 13.523 A
开路电压 (Voc)
0.72 V 0.721 V 0.722 V 0.723 V 0.723 V 0.724 V 0.724 V 0.725 V 0.726 V 0.726 V 0.727 V 0.728 V
短路电流 (Isc)
13.693 A 13.695 A 13.699 A 13.704 A 13.705 A 13.706 A 13.706 A 13.709 A 13.712 A 13.712 A 13.712 A 13.714 A
电池片效率
24.5 % 24.6 % 24.7 % 24.8 % 24.9 % 25 % 25.1 % 25.2 % 25.3 % 25.4 % 25.5 % 25.6 %
填充因子 (FF)
82.04 % 82.25 % 82.45 % 82.64 % 82.96 % 83.18 % 83.51 % 83.71 % 83.9 % 84.24 % 84.45 % 84.66 %

温度系数(Pmax) -0.38 %/˚C
温度系数(Voc) -0.3 %/˚C
温度系数(Isc) 0.048 %/˚C

下载公司产品详情

G-STAR Pte. Ltd.

Click to show company phone
https://www.gstarsolar.com
新加坡
60 Paya Lebar Road #06-12 Paya Lebar Square Singapore 409051
母公司: Standard Energy
注意: 您的询盘将直接发送至G-STAR Pte. Ltd.
公司描述

G-STAR, founded in 2019 and headquartered in Singapore, is committed to being a trusted global provider of clean energy solutions. With a focus on both PV material manufacturing and PV system services, G-STAR aims to develop sustainable clean energy ecosystems worldwide.

G-STAR maintains a global strategy with a "1+N" model, one headquarters in Singapore, with N bases covering the United States, China, India, Mexico, Thailand, Indonesia, Laos, the Philippines, and Egypt. By 2025, G-STAR's integrated production capacity in Southeast Asia is expected to reach 3GW, and the total capacity is 17.5GW.

G-STAR's PV material manufacturing business primarily focuses on the production and processing of silicon materials, including silicon pulling and N-type silicon wafers, as well as metal materials production, including frames and mounting systems. The PV system services encompass the manufacturing of solar modules using N-type technology, providing a comprehensive range of PV products, from R&D to production and sales, catering to global markets including North America, Europe, the Asia-Pacific region, and Africa.

By integrating the PV supply chain to shape an integrated solar future, G-STAR is dedicated to pioneering a sustainable energy landscape that harnesses the full potential of solar power, fostering a brighter, cleaner, and more interconnected world.
