DH series

深圳市大写科技有限公司
价 格:
建议零售起价 ¥405 / 台 *
技术类型: PWM
产品质量保证: --
地区: 中国大陆 中国大陆
联系生产商
注意: 您的询盘将直接发送至深圳市大写科技有限公司

描述:

  • Tailored for streetlights, solar systems, and BSS

  • Utilizes PWM technology

  • Achieves an impressive 96% efficiency

  • Supports a maximum battery charge current of up to 20A

  • Compatible with both AGM and LiFePO4 batteries

  • Boasts an IP65 waterproof rating

  • Equipped with built-in safety features

产品特点

产品型号
DH60 DH100 DH120 50A 60A M340
价格 (建议零售价)
¥405 / 台 * ¥542 / 台 * ¥571 / 台 * ¥643 / 台 * ¥708 / 台 * ¥405 / 台 *
电性能参数
最大太阳能输入功率
40 / 60 W 50 / 100 W 60 / 120 W 600 / 1200 / 1800 / 2400 W 720 / 1440 / 2160 / 2880 W 60 W
电压@最大太阳能输入功率
55 VDC 55 VDC 55 VDC
最大光伏输入电压
12 V 24 V 24 V 160 V 160 V
标称系统(电池)电压
12 / 24 V 12 / 24 V 12 / 24 / 36 / 48 V 12 / 24 / 36 / 48 V 12 / 24 / 36 / 48 V 3.2 / 3.7 V
最大电池充电电流
10 A 15 A 20 A 50 A 60 A 15 A
峰值转换效率
96.00 % 96.00 % 96.00 % 96.00 % 96.00 % 96.00 %
一般参数
尺寸(高/宽/厚)
82x58x20 mm 82x100x20 mm 82x100x20 mm 235x190x100 mm 235x190x100 mm 101x82x23.5 mm
重量
0.15 Kg 0.28 Kg 0.28 Kg 2.20 Kg 2.50 Kg 0.26 Kg
电池类型 AGM
充电算法 4 Stage
防护等级 IP 65
工作温度 -35 ~ +65 °C
通信端口 RS 485, WLAN
显示屏 LED
语言 英语
温度传感器
冷却方式 自然冷却
防护性能
防护性能 短路保护, PV反接保护, PV过压保护, 夜间PV反向电流保护, 电池反接保护, 过载保护, 过充电保护, 过放电保护, 过温保护
PDF
下载公司产品详情

MPPT Solar Charge Controller

Solar Street light MPPT controller

Solar charge controller for solar system

深圳市大写科技有限公司

Click to show company phone
www.daxieworld.cn
中国大陆
No.604, Zhoushi Road, Bao'an District, Shenzhen, Guangdong
员工数: 1,000
注意: 您的询盘将直接发送至深圳市大写科技有限公司
公司描述

We, Shenzhen Daxie Technology Co Ltd. Which can OEM as your requestment of the solar energy products. Globe Fortune 500′ Choice - Shenzhen Daxie Technology Co Ltd. The Company is integrated enterprise with R& D, Production, sales of High Technology Solar Street Lights, Solar Storage battery ,Solar Inverter ,Solar Panel and other Solar Series products.

Our own brand name is Daxieworld Employees above 100people, factory area 3000 square meters, the quantity of the technicians and expert reach 15% of our staff, Daxieworld also collaborate with many famous universities, built the production -learning and research strategic partnership with them. Until now, We already passed the ISO9001 Quality management system certification, CE, RoHS, SASO, IEC, Waterproof certificate etc
