WVC 300/350W

卡司特讯技术(深圳)有限公司
技术
类型
微型逆变器
工作温度范围
工作温度范围
-20 ~ +50 ℃
地区
地区
中国大陆 中国大陆
重量
重量
0.82 kg
产品质量保证
产品质量保证
~ 10 年
功率范围
功率范围
0.3 ~ 0.35 kW
频率
频率
50Hz, 60Hz
效率
效率
99.7 %
protection_class
防护等级
IP67
transformer
变压器
无变压器
no_of_feedin_phases
相数
单相
mpp_voltage_range
MPP(T)电压范围
30~60 V
联系生产商
注意: 您的询盘将直接发送至卡司特讯技术(深圳)有限公司

产品特点

产品型号
WVC300 WVC350

产品质量保证 (最低)
10 年

最大输入功率
0.375 kW 0.435 kW
最大输入电压
60 V 60 V
最大输入电流
13.7 A 18 A
额定直流电流
15 A 16 A
MPP(T)电压范围
30~60 V 30~60 V

最大输出功率
0.3 kW 0.35 kW
交流电压范围
120~230 V 120~230 V
标称交流电压
120, 230 V 120, 230 V
频率范围
50-60 Hz 50-60 Hz
频率
50, 60 Hz 50, 60 Hz
总谐波失真 (THDi)
< 3 % < 3 %
相数
1 1
最大效率
99.7 % 99.7 %
欧洲效率
92.5 % 92.5 %

尺寸(高/宽/厚)
165x176x38 mm 165x176x38 mm
重量
0.82 kg 0.82 kg
工作温度范围 -20 ~ +50 ℃
变压器 无变压器
防护等级 IP67
散热方式 自然冷却
通讯接口 Bluetooth, WLAN
显示屏 None

防护性能 短路保护
