KST-1P Single Axis Solar Tracking System

厦门科盛金属科技有限公司
价 格:
起价 ¥0.763 / Wp
起价 ¥1,510 / 6 块组件
地区: 中国大陆 中国大陆
联系生产商
注意: 您的询盘将直接发送至厦门科盛金属科技有限公司

描述:

  • The tracking accuracy can reach ±1 degree.

  • It can be flexibly arranged according to the terrain.

  • Good terrain adaptability.

  • Modular design, convenient loading and unloading, low maintenance cost, and high maintenance efficiency.

产品特点

产品型号
KST-2P
产品质量保证 10 年
系统概述
类型 地面型
支架系统排列方式 按行排,按列排
组件边框 有边框,无边框
组件排列方向 纵向
倾斜角度
45-60 °
PDF
下载公司产品详情

Product Details

Product Description

Kseng's KST series solar tracking system has a distributed actuation architecture, enabling each row to be independently controlled by its own motor with the tracking method “Astronomical algorithm + closed-loop control”. The system is accurate and reliable, has a real-time closed-loop feedback tracking angle, and automatic tracking, without the need for human intervention.

Specifications

Tracking Structure Parameters

Tracking Technology

Single-Horizontal flat single-axis tracking system

Maximum capacity per row

PV-Modules quantity per row

90 PCS (1Px90)

Tracking range

Tracking accuracy

±1°

Terrain Adaptability

Protection of wind speed

18 m/s

Foundation form

Tracking Controller Parameters

Control system

MCU

Communication type

Night stow mode

Have

Backtracking algorithm

Overload prevention

Have

Self trouble checking

System voltage

DC24

Drive System

Power Acquisition Mode

External Supply/Self-Powered supply

Control algorithm

Solar Tracking System Types

We have three types of solar tracking systems for you to choose from.

1. KST-1P Solar Tracking System

KST-1P solar tracking system is a single row solar tracker product with 1 unit drive.
Control System: MCU
Drive system: Slewing drive
System Voltage: DC 24V
Datefeed: RS485 or Wireless Zigbee
Tracking accuracy: ±1° Tracking
Range: ±45° to ±60°

2. KST-2P Solar Tracker

KST-2P solar tracker is a double row solar tracker product with 1 unit drive.

Control System: MCU

Drive system: Slewing drive

System Voltage: DC 24V

Datefeed: RS485 or Wireless Zigbee

Tracking accuracy: ±1°

Tracking Range: ±45° to ±60°

3. KST-2PM Smart Tracking Mounting System

KST-2PM solar tracker is a double row solar tracker product with 2-4 unit drive (customizable).

Control System: MCU

Drive system: Slewing drive

System Voltage: DC 24V

Datefeed: RS485 or Wireless Zigbee

Tracking accuracy: ±1°

Tracking Range: ±45° to ±60°

Main Structural Parts

1. Control system

a. Astronomical algorithm + AI tracking.

b. String self-powered or AC powered.

c. Wireless communication or wired communication.

d. Low power consumption(0.6kwh/per day/MW).

2. Drive device

a. Dual-drive design.

b. CE & UL Certificate.

c. Protection level IP66.

d. Adopt modular design, can improve maintenance efficiency.

3. Spindle

a. Adopt the largest section specification in the industry, stronger structure.

b. Reduced amplitude and human torsion, improve wind resistance.

4. Bearing

a. Adopt international first-class brand raw materials.

b. Self-lubricating, anti-uv weatherability.

c. UL Cetificate.

d. Removable design, convenient operation and maintenance.

5. Rail

a. The installation is simple and convenient.

b. The components are fixed by bolt, stable and reliable.

6. Pillar

a. High-quality L-shaped steel with large cross-section.

b. Improve the rigidity of the system.

Advantages

1. System damping ratio is greater, can reduce the component amplitude by 50%.

2. Spindle force can reduce 40%.

3. Reduce the force on the drive column by 50%.

4. Reduce spindle torsion angle by 60%.

5. Better system wind resistance.

Terrain Adaptability

1. Flexible arrangement, make full use of irregular land and can improve land utilization.

2. North and South can adapt to 20% slope.

3. Unlimited slope in the east-west.

CPP Wind Tunnel Test

Kseng established a partnership with CPP Wind Engineering, the first American company to provide wind engineering services to architects and engineers. Together, the companies combined the frequency and characteristics of damping ratio of the KS-tracker tracking system, studied the results caused by the KS-tracker system under the action of aerodynamics, and analyzed the influence and instability during the operation of the system.

Tracking Product Certificates

The Ksheng tracking products have passed international standard certifications, such as SGS, CPP, TUV, UL, IEC, etc.

Project Cases

About the Company

Xiamen Kseng Metal Tech Co., Ltd. not only owns a first-class management and technical team, but is also a national high-tech enterprise. Every year, it invests massive capitals to research, exploits new products and purchases new testing equipment including salt spray testers, mechanical testers, etc. With continuous innovation in practical structure and system performance, Kseng own more than 100 utility model patents. Our product structure design absolutely conforms to AS/NZS 1170 standard, JISC8955-2017 standard, European TUV test and SGS certification. We aim to provide safe, reliable and high quality technical solutions for customers and adhere to the phrase, “Kseng Products, Be Trustworthy”. We will continue to do these until the future.
Moreover, Kseng has its own factory with an area of 31000 square meters. We continue to be competitive in terms of product quality, purchasing raw materials from renowned corporations and strictly supervising the quality and delivery. The current production line is divided into two: the first one is for solar mounting brackets, while the second one is for ground screws. We adopt standard manufacturing processes, focusing on quality supervision according to the ISO9001 quality management system and strictly conduct operations through the 6S management system, wherein we implement the double inspection standard. We aim to promote our motto in the PV industry: “Kseng Products, Your Choice.”

Our Office

Factory&Sample room

Solar PV Mounting Manufacturing Process Diagram

Ground Screw Manufacturing Process Diagram

Exhibitions

Certifications

FAQ

厦门科盛金属科技有限公司

+86 592 5779073
www.xmkseng.com
中国大陆
福建省厦门湖里区枋湖北二路891号汇鑫财富大厦6-8楼
员工数: 400
注意: 您的询盘将直接发送至厦门科盛金属科技有限公司

有用联系人

公司描述

Verified Pro Supplier KSENG Solar specializes in providing solar racking and tracking systems for residential, commercial, and utility-scale solar applications.Kseng European warehouse in Poland and Holland.

Driven by the mission of “Empowering our world with clean energy ”, Kseng Solar has increased its global presence with branches and offices in Netherlands, South Korea, Japan, Australia, Malaysia, Hong Kong S.A.R, and other countries and regions. And it has up to 6.55GW annual production capacity with manufacturing bases in Indonesia, Malaysia, and China.

Since the inception of 2015, Kseng Solar has a proven track record as the ideal racking brand for its strong engineering, manufacturing, and customer service capability. With its own manufacturing base to conduct strict quality control and numerous international standards accreditations, Kseng Solar has accomplished nearly 6.55GW of solar racking shipments by the end of 2022. It has ranked No.1 in Korean solar racking market and keeps the best annual growth rate for seven consecutive years in Japan’s solar racking market.

产品视频

其他办事处

国家:
韩国
地址:
306ho, 7-19, Cheongna Canal-ro 260beon-gil, Seo-gu, Incheon, Republic Of Korea
产品
Introduction

Kseng Solar is a total solutions provider that offers solar racking and tracking systems for residential, commercial, industrial and utility-scale solar applications.

Driven by the mission of "Empowering our world with clean energy”, Kseng Solar has increased its global presence with branches and offices in South Korea, Japan, Australia, Malaysia, Vietnam, Hong Kong S.A.R and other countries and regions. It has up to 6 GW annual production capacity with manufacturing bases in Indonesia, Malaysia, Fujian and Tianjin.

Since its inception in 2015, Kseng Solar has a proven track record as an ideal racking brand for its strong engineering, manufacturing and customer service capability. With its manufacturing base to conduct strict quality control and numerous international standards accreditation, Kseng Solar has accomplished more than 6 GW of solar racking shipments by the end of 2021. It has ranked No.1 in Korea’s solar racking market and keeps the best annual growth rate for six consecutive years in the Japanese market.

Main Products
Our Factory

We have two production lines. The first one is for solar mounting systems and the one is for ground screws.

1. Solar PV Mounting Manufacturing Process Diagram
2. Ground Screw Manufacturing Process Diagram
Our Office
Certifications and Patents

Kseng has obtained nearly 100 utility model patents. The products have also been approved by AS/NZS 1170, TUV, UL, CE, CPP, and ISO 9001 quality management standards and other internationally authorized certifications.

Enterprise Honor
Kseng has won the honour of Xiamen Municipal High-tech Enterprise as one of the top 10 PV mounting suppliers.
Exhibitions
Projects
