AS-6M144-HC-435W~465W

Amerisolar
价 格:
起价 ¥1.71 / Wp *
类型: 单晶硅
功率范围: 435 ~ 465 Wp
地区: 中国大陆 中国大陆
注意: 您的询盘将直接发送至Amerisolar

描述:

The high module conversion efficiency of up to 21.27% by using innovative Half-cell design and multi-busbar (MBB) cell technology

Low-temperature coefficient and excellent performance under high temperatures and low light conditions

A robust aluminium frame ensures the modules withstand wind loads up to 2400Pa and snow loads up to 5400Pa

PID resistance

产品特点

产品型号
435W 440W 445W 450W 455W 460W 465W
质量保证
产品质量保证 20 年
功率输出保证 10年期90%输出功率保证,30年期80%输出功率保证
电性能参数(STC)
峰值功率 (Pmax)
435 Wp 440 Wp 445 Wp 450 Wp 455 Wp 460 Wp 465 Wp
峰值工作电压(Vmpp)
41.2 V 41.4 V 41.6 V 41.8 V 42 V 42.2 V 42.4 V
峰值工作电流(Impp)
10.56 A 10.63 A 10.7 A 10.77 A 10.84 A 10.91 A 10.97 A
开路电压(Voc)
49.6 V 49.8 V 50 V 50.2 V 50.4 V 50.6 V 50.8 V
短路电流(Isc)
11.1 A 11.16 A 11.22 A 11.28 A 11.34 A 11.4 A 11.46 A
组件效率
19.9 % 20.13 % 20.36 % 20.58 % 20.81 % 21.04 % 21.27 %
  标准测试条件(STC):太阳能辐射通量1000W/m2,大气参数1.5,组件温度25℃。
电性能参数(NOCT)
峰值功率 (Pmax)
323 Wp 327 Wp 331 Wp 335 Wp 339 Wp 343 Wp 347 Wp
峰值工作电压(Vmpp)
37.4 V 37.6 V 37.8 V 38 V 38.2 V 38.4 V 38.6 V
峰值工作电流(Impp)
8.64 A 8.7 A 8.76 A 8.82 A 8.88 A 8.94 A 8.99 A
开路电压(Voc)
45.6 V 45.8 V 46 V 46.2 V 46.4 V 46.6 V 46.8 V
短路电流(Isc)
8.99 A 9.04 A 9.1 A 9.14 A 9.19 A 9.24 A 9.29 A
最大耐久温度 43±2 °C
  电池片标称工作温度(NOCT):太阳能辐射通量800W/m2,大气参数1.5,环境温度20℃,风速1 m/s。
温度特性
工作温度 -40~85 °C
温度系数(Pmax) -0.36 %/°C
温度系数(Voc) -0.28 %/°C
温度系数(Isc) 0.05 %/°C
系统集成参数
最大系统电压 1500 V
保险丝额定电流 20 A
物理参数
组件尺寸(高/宽/厚) 2102x1040x35 mm
重量 24 kg
电池片类型 单晶硅
电池片数量 144
玻璃类型 钢化,防反射镀膜
玻璃厚度 3.2 mm
边框类型 阳极氧化铝合金
旁路二极管数 3
接线盒防护等级 IP 68
连接器类型 MC4
电缆截面 4 mm2
电缆长度 1400 mm
