JFS2-144-18X 530-550W

安徽晶飞科技有限公司
价 格:
起价 ¥0.800 / Wp *
电 池 技 术:
功率范围: 530 ~ 550 Wp
地区: 中国大陆 中国大陆
联系生产商
注意: 您的询盘将直接发送至安徽晶飞科技有限公司

描述:

  • Mono PERC Cells with Half-cut Technology

  • Higher Power Output

  • PID Resistant

  • High Efficiency up to 21.1%

  • 0~+5W Positive Power Tolerance

  • 12 Years Materials 25 Years Linear Output Warranty

产品特点

类型 单晶硅
产品型号
JFS2-144--530M JFS2-144--535M JFS2-144--540M JFS2-144--545M JFS2-144--550M
质量保证
产品质量保证 12 年
功率输出保证 10年期90%输出功率保证,25年期85%输出功率保证
电性能参数(STC)
峰值功率 (Pmax)
530 Wp 535 Wp 540 Wp 545 Wp 550 Wp
峰值工作电压(Vmpp)
41.35 V 41.5 V 41.65 V 41.8 V 41.95 V
峰值工作电流(Impp)
12.82 A 12.9 A 12.97 A 13.04 A 13.11 A
开路电压(Voc)
49.2 V 49.35 V 49.5 V 49.65 V 49.8 V
短路电流(Isc)
13.71 A 13.78 A 13.85 A 13.92 A 13.99 A
组件效率
20.5 % 20.7 % 20.9 % 21.1 % 21.3 %
功率偏差(正)
+ 1 % + 1 % + 1 % + 1 % + 1 %
  标准测试条件(STC):太阳能辐射通量1000W/m2,大气参数1.5,组件温度25℃。
电性能参数(NOCT)
峰值功率 (Pmax)
395.8 Wp 399.5 Wp 403.3 Wp 407 Wp 410.7 Wp
峰值工作电压(Vmpp)
38.5 V 38.64 V 38.78 V 38.92 V 39.04 V
峰值工作电流(Impp)
10.28 A 10.34 A 10.4 A 10.46 A 10.52 A
开路电压(Voc)
46.16 V 46.26 V 46.41 V 46.55 V 46.69 V
短路电流(Isc)
11.09 A 11.15 A 11.2 A 11.25 A 11.41 A
最大耐久温度 45±2 °C
  电池片标称工作温度(NOCT):太阳能辐射通量800W/m2,大气参数1.5,环境温度20℃,风速1 m/s。
温度特性
工作温度 -40~85 °C
温度系数(Pmax) -0.35 %/°C
温度系数(Voc) -0.27 %/°C
温度系数(Isc) 0.048 %/°C
系统集成参数
最大系统电压 1500 V
保险丝额定电流 25 A
物理参数
组件尺寸(高/宽/厚) 2279x1134x35 mm
重量 27.2 kg
电池片规格 182×182 mm
电池片数量 144
玻璃类型 钢化
玻璃厚度 3.2 mm
密封材料类型 EVA
边框类型 阳极氧化铝
旁路二极管数 3
接线盒防护等级 IP 68
连接器类型 MC4
电缆截面 4 mm2
电缆长度 300 mm
PDF
下载公司产品详情
About Us
Main Products
Projects

安徽晶飞科技有限公司

Click to show company phone
https://www.jf-solartech.com
中国大陆
No.9, Taiyanghe West Road, He County Economic Development Zone, Ma'anshan, Anhui, 238200
员工数: 2,000
母公司: Standard Enterprise (Group)
注意: 您的询盘将直接发送至安徽晶飞科技有限公司

晶体硅

产量 (MW)/: MWp
单晶硅
功 率 范 围(Wp): 350-605
公司描述

Anhui JF Solar Technology Co., Ltd., a distinguished arm of the Stand Enterprise Group, is an industry-leading manufacturer of high-end solar PV modules. Strategically located in Ma’anshan City, Anhui Province, our 200,000-square-meter facility, backed by a $350 million investment, houses the most advanced technology in the field.

With over 12 years of experience, we annually produce 2GW of high-efficiency solar modules. JF Solar's broad spectrum of energy solutions encompasses clean energy development, construction, operation, and management. We specialize in solar module production, integrated energy systems investment, and construction, inclusive of solar power, energy storage, distribution networks, microgrids, and multi-energy complementation.

Guided by our mission to illuminate the world with solar energy, we aim to fortify our position as a globally recognized, customer-centric enterprise, pioneering innovations in clean power conversion technology. At JF Solar, we deliver unmatched value, merging superior quality with cost efficiency. We warmly invite potential collaborators to join us in shaping a sustainable future.
