ZPM525~550MH5-72

Name: ZPM525~550MH5-72
Brand: Zonergy
SKU: 49576
Availability: OutOfStock

Zonergy Corporation

地区

中国大陆

重量

28.5 kg

产品质量保证

10 年

功率输出保证

80 % 25年年限质保

尺寸

2279x1134x35 mm

玻璃厚度

3.2 mm

电池片数量

144

联系生产商

该产品不再生产。

高输出功率
抗PID特性
热点效应
风荷载（2400 帕斯卡）和雪荷载（5400 帕斯卡）

产品信息
公司档案页

产品特点

类型

单晶硅

产品型号

ZPM 525 72p

ZPM 530 72p

ZPM 535 72p

ZPM 540 72p

ZPM 545 72p

ZPM 550 72p

产品质量保证

10 年

功率输出保证

80 % 25年年限质保

0.8 %

电性能参数（STC）

峰值功率（Pmax）

525 Wp

530 Wp

535 Wp

540 Wp

545 Wp

550 Wp

峰值工作电压（Vmpp）

41.1 V

41.27 V

41.45 V

41.62 V

41.8 V

41.97 V

峰值工作电流（Impp）

12.78 A

12.85 A

12.91 A

12.98 A

13.05 A

13.11 A

开路电压（Voc）

48.95 V

49.15 V

49.35 V

49.55 V

49.75 V

49.95 V

短路电流（Isc）

13.67 A

13.74 A

13.82 A

13.89 A

13.97 A

14.05 A

组件效率

20.3 %

20.5 %

20.7 %

20.9 %

21.1 %

21.3 %

电性能参数（NOCT）

峰值功率（Pmax）

396 Wp

400 Wp

404 Wp

407 Wp

411 Wp

414 Wp

峰值工作电压（Vmpp）

38.35 V

38.55 V

38.76 V

38.95 V

39.16 V

39.31 V

峰值工作电流（Impp）

10.33 A

10.38 A

10.43 A

10.46 A

10.5 A

10.53 A

开路电压（Voc）

46 V

46.13 V

46.26 V

46.38 V

46.5 V

46.63 V

短路电流（Isc）

10.95 A

10.99 A

11.03 A

11.08 A

11.12 A

11.17 A

工作温度

-40 - 85 °C

最大系统电压

1500 V

组件尺寸（高/宽/厚）

2279x1134x35 mm

重量

28.5 kg

电池片规格

182×182 mm

电池片数量

144

玻璃厚度

3.2 mm

密封材料类型

EVA

边框类型

阳极氧化铝

旁路二极管数

接线盒防护等级

IP 68

连接器类型

MC4

电缆截面

4 mm²

电缆长度

400 mm

下载公司产品详情

数据表

Introduction

In recent years, relying on its own complete industrial chain, high-level R&D team, and strong strategic alliance, Zonergy has ranked first in the world in the construction scale of off-grid optical storage smart microgrid projects, and its technical solutions and implementation capabilities are leading in the world.

On this basis, Zonergy has made an in-depth layout in the field of optical storage smart microgrids and has successively established world-leading R&D and production bases - Zigong R&D Base, Chengdu Research Institute, and Shenzhen Research Institute.

Among them, the Zigong R&D base covers an area of about 140 mu. The base has been awarded the license: Sichuan Optical Storage Smart Microgrid Engineering Technology Research Center, and will be selected as a major project in the Sichuan-Chongqing economic circle in 2021.

After the base is completed, it will become an important force in my country's optical storage smart microgrid technology, product cooperative development, and transformation of scientific and technological achievements, as well as a platform for related technical exchanges and cooperation, as well as a training base for core talents, promoting the technological progress of the industry and driving the coordinated development of surrounding areas.
