ZPM530-550HG-72 Double-Glass Bifacial Half-Cell

Name: ZPM530-550HG-72 Double-Glass Bifacial Half-Cell
Brand: Zonergy
SKU: 55436
Availability: OutOfStock

Zonergy Corporation

技术

双面, 背钝化 (PERC)

地区

中国大陆

重量

32 kg

产品质量保证

12 年

功率输出保证

84.95 % 30年年限质保

尺寸

2285x1134x35 mm

玻璃厚度

2 mm

温度系数（Pmax）

-0.350 %/°C

联系生产商

该产品不再生产。

产品信息
公司档案页

产品特点

产品型号

ZPM530HG-72

ZPM535HG-72

ZPM540HG-72

ZPM545HG-72

ZPM550HG-72

产品质量保证

12 年

功率输出保证

84.95 % 30年年限质保

0.5 %

功率偏差

-5 ~ +5 %

电性能参数（STC）

峰值功率（Pmax）

530 Wp

535 Wp

540 Wp

545 Wp

550 Wp

峰值工作电压（Vmpp）

40.73 V

40.88 V

41.03 V

41.18 V

41.31 V

峰值工作电流（Impp）

13.02 A

13.1 A

13.17 A

13.24 A

13.31 A

开路电压（Voc）

49.23 V

49.38 V

49.53 V

49.68 V

49.83 V

短路电流（Isc）

13.46 A

13.54 A

13.63 A

13.71 A

13.8 A

组件效率

20.45 %

20.64 %

20.84 %

21.03 %

21.22 %

电性能参数（NOCT）

峰值功率（Pmax）

396 Wp

400 Wp

404 Wp

408 Wp

412 Wp

峰值工作电压（Vmpp）

37.49 V

37.64 V

37.79 V

37.94 V

38.05 V

峰值工作电流（Impp）

10.57 A

10.64 A

10.7 A

10.77 A

10.83 A

开路电压（Voc）

45.26 V

45.41 V

45.56 V

45.71 V

45.85 V

短路电流（Isc）

11.22 A

11.29 A

11.37 A

11.44 A

11.53 A

最大耐久温度

41±3 °C

工作温度

-40 - 85 °C

温度系数（Pmax）

-0.350 %/°C

温度系数（Voc）

-0.270 %/°C

温度系数（Isc）

0.048 %/°C

最大系统电压

1500 V

组件尺寸（高/宽/厚）

2285x1134x35 mm

重量

32 kg

玻璃类型

钢化

玻璃厚度

2 mm

边框类型

阳极氧化铝

接线盒防护等级

IP 68

连接器类型

MC4

电缆截面

4 mm²

电缆长度

2500 mm

下载公司产品详情

数据表

Introduction

In recent years, relying on its own complete industrial chain, high-level R&D team, and strong strategic alliance, Zonergy has ranked first in the world in the construction scale of off-grid optical storage smart microgrid projects, and its technical solutions and implementation capabilities are leading in the world.

On this basis, Zonergy has made an in-depth layout in the field of optical storage smart microgrids and has successively established world-leading R&D and production bases - Zigong R&D Base, Chengdu Research Institute, and Shenzhen Research Institute.

Among them, the Zigong R&D base covers an area of about 140 mu. The base has been awarded the license: Sichuan Optical Storage Smart Microgrid Engineering Technology Research Center and will be selected as a major project in the Sichuan-Chongqing economic circle in 2021.

After the base is completed, it will become an important force in my country's optical storage smart microgrid technology, product cooperative development, and transformation of scientific and technological achievements, as well as a platform for related technical exchanges and cooperation, as well as a training base for core talents, promoting the technological progress of the industry and driving the coordinated development of surrounding areas.
