Hitouch5N HN18-72HT 565-585

汉伏能源技术（南京）有限公司

类型：	TOPCon
功率范围：	565 ~ 585 Wp
地区：	中国大陆

注意： 您的询盘将直接发送至汉伏能源技术（南京）有限公司。

描述：

产品信息
公司档案页

产品特点

产品型号

HN18-72HT565

HN18-72HT570

HN18-72HT575

HN18-72HT580

HN18-72HT585

质量保证

产品质量保证

15 年

功率输出保证

30年期87.4%输出功率保证

电性能参数（STC）

峰值功率（Pmax）

565 Wp

570 Wp

575 Wp

580 Wp

585 Wp

峰值工作电压（Vmpp）

42.6 V

42.8 V

43 V

43.2 V

43.4 V

峰值工作电流（Impp）

13.27 A

13.32 A

13.38 A

13.43 A

13.49 A

开路电压（Voc）

50.8 V

51 V

51.2 V

51.4 V

51.6 V

短路电流（Isc）

14.05 A

14.11 A

14.17 A

14.23 A

14.3 A

组件效率

21.87 %

22.07 %

22.26 %

22.45 %

22.65 %

标准测试条件（STC）：太阳能辐射通量1000W/m²，大气参数1.5，组件温度25℃。

电性能参数（NOCT）

峰值功率（Pmax）

428 Wp

432 Wp

436 Wp

440 Wp

445 Wp

峰值工作电压（Vmpp）

40 V

40.2 V

40.4 V

40.6 V

40.8 V

峰值工作电流（Impp）

10.7 A

10.74 A

10.79 A

10.84 A

10.92 A

开路电压（Voc）

48.6 V

48.7 V

48.9 V

49.1 V

49.3 V

短路电流（Isc）

11.33 A

11.38 A

11.42 A

11.47 A

11.53 A

最大耐久温度

42±2 °C

电池片标称工作温度（NOCT）：太阳能辐射通量800W/m²，大气参数1.5，环境温度20℃，风速1 m/s。

温度特性

工作温度

-40~85 °C

温度系数（Pmax）

-0.31 %/°C

温度系数（Voc）

-0.26 %/°C

温度系数（Isc）

0.045 %/°C

系统集成参数

最大系统电压

1500 V

保险丝额定电流

30 A

物理参数

组件尺寸（高/宽/厚）

2278x1134x30 mm

重量

32.5 kg

电池片类型

TOPCon

电池片规格

182x182 mm

电池片数量

144

玻璃厚度

2 mm

密封材料类型

EVA

边框类型

阳极氧化铝合金

接线盒防护等级

IP 68

连接器类型

MC4

电缆截面

4 mm²

电缆长度

300 mm
