HW-M10/144H(610-630) Bifacial
Hiwatt Solar Limited
|
每件价格
|
|||
| 最低订购量 | 100-999 件 | 1000-9999 件 | |
| 600 | ¥382 | ¥375 | |
|
每件价格
每件价格
|
|||
| 最低订购量 | 1-9 件 | 10-99 件 | 100+ 件 |
| 630 | ¥410 | ¥403 | ¥396 |
产品特点
| 类型 | 单晶硅 | |||||
|---|---|---|---|---|---|---|
| 产品型号 |
|
|||||
| 产品质量保证 | 12 年 | |||||
| 功率输出保证 | 84.8 % 25年年限质保 | |||||
| 0.61 % | ||||||
| 功率偏差 | 0 ~ +0.5 % | |||||
| 电性能参数（STC） | ||||||
| 峰值功率 （Pmax） |
|
|||||
| 峰值工作电压（Vmpp） |
|
|||||
| 峰值工作电流（Impp） |
|
|||||
| 开路电压（Voc） |
|
|||||
| 短路电流（Isc） |
|
|||||
| 组件效率 |
|
|||||
| 电性能参数（NOCT） | ||||||
| 峰值功率 （Pmax） |
|
|||||
| 峰值工作电压（Vmpp） |
|
|||||
| 峰值工作电流（Impp） |
|
|||||
| 开路电压（Voc） |
|
|||||
| 短路电流（Isc） |
|
|||||
| 最大耐久温度 | 43±2 °C | |||||
| 工作温度 | -40 - 85 °C | |||||
| 温度系数（Pmax） | -0.34 %/°C | |||||
| 温度系数（Voc） | -0.25 %/°C | |||||
| 温度系数（Isc） | 0.04 %/°C | |||||
| 最大系统电压 | 1500 V | |||||
| 保险丝额定电流 | 30 A | |||||
| 组件尺寸（高/宽/厚） | 2382x1134x30 mm | |||||
| 重量 | 32.8 kg | |||||
| 电池片数量 | 144 | |||||
| 旁路二极管数 | 3 | |||||
| 接线盒防护等级 | IP 68 | |||||
| 电缆截面 | 4 mm2 | |||||
| 下载公司产品详情 | ||||||
N-type High Efficiency Solar Module
HJT 2.0 Technology
Combining gettering process and single-side μc-Si technology to ensure higher cell efficiency and higher module power
SMBB design with Half-Cut Technology
Shorter current transmission distance, low resistive loss and higher cell efficiency.
Up to 90%Bifaciality
Natural symmetrical bifacial structure bringing more energy yield from the backside.
Suitable for Utility project
Lower BOS cost, Lower LCOE
Excellent power generation performance
0/+5W positive power tolerance
Improved low light irradiance performance and low degradation
Advanced production process
Optimized MBB design
Cell efficiency >23.0%
Stable mechanical performance
Passed rigorous hail test
Withstands 5400Pa snow and 2400Pa wind loads
Superior quality control
Fully automatic production line
100% three times EL and appearance inspection
Hiwatt Solar is a technology company specializing in the research , development, production and sales of solar photovoltaic modules. Hiwatt Solar is a world leading solar module manufacturer and comprehensive solar solution provider.Our solar modules production capacity reaches 2.2GW . We have our own fully automated production line which ensures the quality is strict and stable.we can produce market mainstream solar modules ,including large size 210mm cell solar module power up to 750W plus, MBB, high efficient single glass and double glass bifacial modules, both mono and poly, full cells and half cut cells solar modules.
