Ecox 12V Lifepo4 12V Battery

上海派智能源股份有限公司
标称电压
12.8 V
技术
LFP(磷酸锂铁)
地区
中国大陆 中国大陆
重量
12 ~ 32.5 kg
产品质量保证
3 年
循环寿命
4000@80%DOD
设计寿命
10 年
配置
仅电池
最大放电电流
100 ~ 160 A
每件价格
每件价格
最低订购量 1-299 件 300+ 件
Ecox12100 ¥2,330 ¥1,800
Ecox12100SE ¥2,000 ¥1,470
Ecox12200 ¥2,670 ¥2,130
Ecox 12314 ¥2,670 ¥2,470
联系生产商
该产品不再生产。
磷酸铁锂(LFP)电池化学体系

产品特点

产品型号
Ecox12100 Ecox12100SE Ecox12200 Ecox 12314
产品质量保证 (最低) 3 年
配置 仅电池
储能系统技术 LFP(磷酸锂铁)
安装方式 地板
最大并行单元数 16


标称电压
12.8 V 12.8 V 12.8 V 12.8 V
工作电压范围 14 - 14.4 V
标称容量
100Ah@1hr 100Ah@1hr 200Ah@1hr 314Ah@1hr
标称能量
1.28 kWh 1.28 kWh 2.56 kWh 4.1092 kWh
标称充电电流
50 A 50 A 50 A
最大放电电流
100 A 100 A 100 A 160 A
内阻
10 mΩ 10 mΩ 10 mΩ
设计寿命
10 年 10 年 10 年
循环寿命 4000@80%DOD
循环效率 99 %

工作温度范围 -20 ~ +50 ℃

尺寸(长*宽*高)
325x173.5x238 mm 300x160x210 mm 459x190x215 mm 340x280x235 mm
重量
12 Kg 12 Kg 20.9 Kg 32.5 Kg
IP 等级 IP20,IP65,IP67
最高运行海拔 4000 m
冷却方式 自然冷却
通信方式 WiFi
监控 应用程序

下载公司产品详情
公司图标

上海派智能源股份有限公司

Click to show company phone
https://www.pytesgroup.com
中国大陆 中国大陆
上海市奉贤区金钱公路3492号
员工数: 1,000
location
该产品不再生产。

有用联系人

公司描述

As a leading lithium battery solution provider, Pytes is committed to providing energy storage solutions. Started in 2004, with continuous support and technical experience, more than 1,000 Pytes employees are now working to build a greener future.

Grasping the general trend of globalization, Pytes not only has multiple production bases in China, but also runs branches, offices and factories in North America, Europe, Vietnam and other sites to achieve multi-regional coverage of the service network, with faster delivery and quicker response.

Creating, Undertaking, Sharing, we practice our philosophy and fulfill the mission that to deliver safe, reliable and affordable clean energy to home and community for a more carbon-free future.
