LNE-N10

苏州潞能能源科技有限公司

电池片类型：	TOPCon
功率范围：	7.86~8.29 Wp
地区：	中国大陆

注意： 您的询盘将直接发送至苏州潞能能源科技有限公司。

描述：

仓库:

苏州

库存量：

3,000 件

仓库地点：	苏州
型号	库存量(件)	联系生产商
7.96	1,000
8.29	2,000

产品信息
公司档案页

产品特点

产品型号

7.86

7.89

7.96

7.92

7.99

8.02

8.06

8.09

8.12

8.16

8.19

8.22

8.25

8.29

产品特点

电池片技术

TOPCon

尺寸

182x182 mm

对角线

247±0.25 mm

电池片厚度

140 ± 14 µm

正面 (-)

栅线宽度

0.036±0.02 mm

背面 (+)

焊垫宽

0.036±0.02 mm

背面电场 (BSF)

铝

电性能参数（STC）

峰值功率 (Pmax)

7.86 W

7.89 W

7.9 W

7.92 W

7.99 W

8.02 W

8.06 W

8.09 W

8.12 W

8.16 W

8.19 W

8.22 W

8.25 W

8.29 W

峰值工作电压 (Vmpp)

0.6024 V

0.6032 V

0.6054 V

0.604 V

0.6059 V

0.6065 V

0.6073 V

0.6081 V

0.6089 V

0.6097 V

0.6106 V

0.6114 V

0.6122 V

0.6131 V

峰值工作电流 (Impp)

13.055 A

13.08 A

13.155 A

13.115 A

13.195 A

13.23 A

13.265 A

13.3 A

13.335 A

13.37 A

13.405 A

13.44 A

13.475 A

13.518 A

开路电压 (Voc)

0.7034 V

0.7042 V

0.7064 V

0.705 V

0.7069 V

0.7075 V

0.7083 V

0.7091 V

0.7099 V

0.7107 V

0.7116 V

0.7124 V

0.7132 V

0.7141 V

短路电流 (Isc)

13.615 A

13.64 A

13.715 A

13.675 A

13.755 A

13.79 A

13.825 A

13.86 A

13.895 A

13.93 A

13.965 A

14 A

14.035 A

14.078 A

电池片效率

23.8 %

23.9 %

24.1 %

24 %

24.2 %

24.3 %

24.4 %

24.5 %

24.6 %

24.7 %

24.8 %

24.9 %

25 %

25.1 %

填充因子 (FF)

82.07 %

82.14 %

82.16 %

82.15 %

82.17 %

82.2 %

82.32 %

82.42 %

82.46 %

温度特性

温度系数（Pmax）

-0.32 %/˚C

温度系数（Voc）

-0.25 %/˚C

温度系数（Isc）

0.045 %/˚C

PDF

下载公司产品详情

Dimension 182mmx182mm±0.25mm，Φ247mm±0.25mm

Cell Thickness 140±14μm

Front side (−)

SiNx AR Coating. The width of the busbar is 0.036±0.02mm

The head of the busbar is forked.

The number of the finger is 132.

The front side of the solar cell is designed as a half sheet.

Back side (+)

SiNx AR Coating. The width and length of the Ag electrode are 0.036±0.02mm.

The number of the aluminum busbar is 16.

The number of the aluminum finger is 146.

Solderability（Peel strength）≥0.5N/mmResults may vary depending on the conditions.
