Trinergy Plus Series

Allis Electric Co., Ltd.
类型: 并网
功率范围: --
地区: 中国台湾 中国台湾
联系生产商
注意: 您的询盘将直接发送至Allis Electric Co., Ltd.

替代产品

Three-phase Hy...

深圳迈格瑞能技术有限公司
  • 类型: 并网,离网,混合
  • 产品质量保证: --
  • 防护等级: IP65
  • 尺寸: 560x530x220 mm
  • 重量: 30 kg

产品特点

产品型号
Trinergy Plus 10KW Trinergy Plus 20KW Trinergy Plus 30KW Trinergy Plus 40KW Trinergy Plus 50KW Trinergy Plus 60KW Trinergy Plus 70KW
质量保证
产品质量保证 (最低)
5 年 5 年 5 年 5 年 5 年 5 年 5 年
输入参数(直流)
最大输入功率
11 kW 20.8 kW 33 kW 55 kW 66 kW 72 kW 77 kW
最大输入电压
1000 V 1000 V 1000 V 1100 V 1100 V 1100 V 1100 V
额定直流电压
580 V 610 V 610 V 740 V 740 V 740 V 740 V
最大输入电流
25 A 50 A 66 A 74 A 90 A 120 A 120 A
MPP(T)电压范围
200~800 V 280~800 V 280~800 V 570~950 V 570~950 V 570~950 V 570~950 V
MPPT数量
2 2 2 1 1 1 1
直流输入连接端数
2 6 6 10 12 14 14
输出参数(交流)
交流电压范围
320~460 V 320~460 V 320~460 V 310~460 V 310~460 V 310~460 V 310~460 V
额定交流电压
400 V 400 V 400 V 400 V 400 V 400 V 400 V
最大输出电流
14 A 32 A 48 A 64 A 80 A 96 A 96 A
频率范围
47.5-61.5 Hz 47.5-61.5 Hz 47-61.5 Hz 47-61.5 Hz 47-61.5 Hz 47-61.5 Hz 47-61.5 Hz
频率
50, 60 Hz 50, 60 Hz 50, 60 Hz 50, 60 Hz 50, 60 Hz 50, 60 Hz 50, 60 Hz
功率因数 (cosθ)
0.8 0.8 0.8 0.8 0.8 0.8 0.8
总谐波失真 (THDi)
< 3 % < 3 % < 3 % < 3 % < 3 % < 3 % < 3 %
相数
3 3 3 3 3 3 3
最大效率
98.3 % 98.4 % 98.5 % 98.9 % 98.9 % 99 % 99 %
欧洲效率
97.8 % 98 % 98 % 98.5 % 98.5 % 98.5 % 98.5 %
一般参数
尺寸(高/宽/厚)
575x360x150 mm 660x520x250 mm 660x520x250 mm 810x645x235 mm 810x645x235 mm 810x645x235 mm 810x645x235 mm
重量
23 kg 52 kg 52 kg 53 kg 53 kg 53 kg 53 kg
夜间损耗
< 0.5 W < 0.5 W < 0.5 W < 0.5 W < 0.5 W < 0.5 W < 0.5 W
噪音干扰级别
< 50 dB(A) < 50 dB(A) < 50 dB(A) < 60 dB(A) < 60 dB(A) < 60 dB(A) < 60 dB(A)
环境温度范围 -25 ~ +60 ℃
变压器 无变压器
防护等级 IP65
相对湿度 0-95 %
通讯接口 RS 485
显示屏 LCD
