Pitched Tile Roof Mounting System

Pitched Roof Tile Mounting System is engineered for the maximum flexibility possible in designing and planning for the commercial and residential roof solar system. It is applicable to install the usual framed module, The special extruded aluminum rail, special D nut module, clamp kit and the various roof hooks can be high pre-assembly and make the installation easy and quick to save your labor cost and time. The customized length can eliminate the weld and cut onsite to keep the high anticorrosive performance, the structure strength and the appearance.

Technical Parameters :

Installation Site: Pitched Roof

Installation Angle: Parallel the roof

Building Height: Upto 20m

Wind Load: Upto 60m/s

Snow Load: Upto 1.5KN/m2

Applicable Module: Framed or Frameless

Module Orientation: Landscape and Portrait

Module Dimension: Applicable to any dimension

Standard Compliance: AS/NZS1170.2 ; SGS and other international standards

Material: Aluminum Alloy 6005-T5, Stainless Steel 304

Color: Natural or customized.

Warranty: 12 years of quality warranty and 20 years service life

Xiamen Large Energy Tech Co., Ltd, is located in the Xiamen China, is a collection of renewable energy investment and PV mounting system production, solar power station service, we are a high-tech enterprise specialized in solar mounting products, Large Energy insists on “professional and innovation” on product R&D and manufacture, so we can provide customers with high quality ,trustable and cost-efficient solar PV mounting system solutions, Large Energy have been taking the leading in the global PV market.

“profession” and “innovate” is our services guide and pursuit. Always adhere to the business philosophy: Professionalism, Sincerity, Win-win situation, to provide professional and quality service. Our corporate culture: Green Life, Continuation of development. Installation Simple, Flexible, and Low-cost Leading solar mounting systems. LARGE Energy have developed series of mounting system, including Roman tile roof mounting systems, Tin roof mounting systems, Flat concrete roof mounting systems, Ground all-aluminum mounting system, Ground Steel mounting systems, Solar farm mounting systems and various mounting components. LARGE Energy solar mounting systems have passed certifications in many countries, including AS/NZS1170.2, SGS, ISO9001 etc. We also have owned several patents of our mounting system and components.
