Pre-assembled Plug and Play Balcony PV Mounting...

Designed specifically for the booming European "Balkonkraftwerk" (Balcony Power Plant) market, our mounting system offers the perfect balance of strength and durability. We combine Robotic-welded Stainless Steel 304 Hooks for maximum safety with Lightweight Aluminum 6005-T5 Rails for ease of handling.

Hybrid Material Advantage:

1. Hooks: Made of high-strength Stainless Steel (SUS304). They resist bending under heavy wind loads and ensure the system stays locked to the railing for 20+ years.

2. Structure: Made of Anodized Aluminum (AL6005-T5). It provides excellent corrosion resistance while keeping the total weight low to protect the balcony structure.

3. Fasteners: All bolts and nuts are Stainless Steel 304, preventing rust even in humid or coastal areas.

   True Universal Fit :

   Our adjustable hook design is compatible with Round, Square, and Flat railings common in Germany, Austria, and France. No need to stock different models for different apartment types.

   Pre-assembled:

   We know that labor cost is high in Europe. Our parts come pre-assembled. No drilling or cutting is required on-site. Just unfold, hook, and lock.

   Microinverter Friendly:

   Includes dedicated mounting positions for mainstream microinverters (compatible with Hoymiles, Deye, APsystems, etc.)

Install Site: High-rise Building Balconies / Garden Fences

Wind Load: Up to 60m/s (Designed for high-wind zones)

Snow Load: 1.4 KN/m²

Tilt Angle: 0° / 0°-15°/ 15°-30°/30°-60° Adjustable (Optional)

Applicable Module: Frame / Frameless (Works with 400W-600W panels)

Standards: AS/NZS 1170, Eurocode, DIN Standards,JIS

Warranty: 10 Years on Material

1. Compact Packing: Rails are segmented or telescoping (optional) to fit into smaller cartons, significantly reducing shipping costs for LCL/FCL orders.

2. Retail Ready: Can be packed in single kits (one carton per system) for direct distribution to end-users.
