N-TopCon Solar Panel Mono 620W-650W Monofacial

江苏奥轩光电科技有限公司
技术
技术
TOPCon, N型
功率范围
功率范围
620 - 650 Wp
地区
地区
中国大陆 中国大陆
重量
重量
29 kg
产品质量保证
产品质量保证
12 年
功率输出保证
功率输出保证
90 % 12年年限质保,80 % 30年年限质保
组件效率
组件效率
22.9 % - 24.1 %
组件尺寸
尺寸
2382x1134x30 mm
玻璃厚度
玻璃厚度
3.2 mm
温度系数(Pmax)
温度系数(Pmax)
-0.30 %/°C
电池片数量
电池片数量
132
价 格:
起价
¥0.589 / Wp*
*
每件价格
每件价格
最低订购量 740-2999 3000-6999 7000+
交货时间 21 days 21 days 21 days
AOX-132G12RHC630W ¥379 ¥375 ¥371
联系生产商
注意: 您的询盘将直接发送至江苏奥轩光电科技有限公司
  • Based on M10-182mm solar cells

  • Higher module quality ensures long-term reliability

  • MBB technology enhances light trapping and current collection for improved module power and reliability

  • Excellent Anti-PID performance guarantee via optimized mass production process and materials control

产品特点

类型 单晶硅
产品型号
AOX-132G12RHC620W AOX-132G12RHC625W AOX-132G12RHC630W AOX-132G12RHC635W AOX-132G12RHC640W AOX-132G12RHC645W AOX-132G12RHC650W

产品质量保证 12 年
功率输出保证 90 % 12年年限质保,80 % 30年年限质保
0.67 %
功率偏差 -3 ~ +3 %
电性能参数(STC)
峰值功率 (Pmax)
620 Wp 625 Wp 630 Wp 635 Wp 640 Wp 645 Wp 650 Wp
峰值工作电压(Vmpp)
41.1 V 41.3 V 41.5 V 41.7 V 41.9 V 42.1 V 42.3 V
峰值工作电流(Impp)
15.09 A 15.13 A 15.18 A 15.23 A 15.28 A 15.33 A 15.37 A
开路电压(Voc)
49.2 V 49.4 V 49.6 V 49.8 V 50 V 50.2 V 50.4 V
短路电流(Isc)
15.94 A 15.98 A 16.03 A 16.08 A 16.14 A 16.19 A 16.23 A
组件效率
22.9 % 23 % 23.3 % 23.5 % 23.7 % 23.9 % 24.1 %
电性能参数(NOCT)
峰值功率 (Pmax)
471 Wp 475 Wp 479 Wp 483 Wp 487 Wp 491 Wp 495 Wp
峰值工作电压(Vmpp)
38.6 V 38.8 V 39 V 39.2 V 39.4 V 39.6 V 39.8 V
峰值工作电流(Impp)
12.2 A 12.24 A 12.28 A 12.32 A 12.36 A 12.4 A 12.44 A
开路电压(Voc)
46.6 V 46.8 V 47 V 47.2 V 47.4 V 47.6 V 47.8 V
短路电流(Isc)
12.89 A 12.93 A 12.97 A 13 A 13.05 A 13.09 A 13.12 A
最大耐久温度 45±2 °C

工作温度 -40 - +85 °C
温度系数(Pmax) -0.30 %/°C
温度系数(Voc) -0.24 %/°C
温度系数(Isc) 0.04 %/°C

最大系统电压 1500 V
保险丝额定电流 30 A

组件尺寸(高/宽/厚) 2382x1134x30 mm
重量 29 kg
电池片规格 182×105 mm
电池片数量 132
玻璃类型 防反射镀膜,钢化
玻璃厚度 3.2 mm
密封材料类型 EVA
背板类型 TPT
边框类型
旁路二极管数 3
接线盒防护等级 IP 68
连接器类型 MC4
电缆截面 4 mm2
电缆长度 300 mm
