GS182M

G-STAR Pte. Ltd.

每件价格
最低订购量	50000+ 件
25.0	¥1.98

注意： 您的询盘将直接发送至无锡施莱德新能源有限公司。

82.18 ~ 88.62 %

24.0 ~ 25.5 %

TOPCon

7.92 ~ 8.39 Wp

182x182 mm

130 µm

0.03±0.015 mm

80.17 - 87.83 %

电池片效率

21.9 - 23 %

7.23 - 7.59 Wp

182x182 mm

电池片厚度

190 ± 30 µm

0.06 mm

1.8 mm

联系生产商

该产品不再生产。

产品信息
公司档案页

产品特点

产品型号

7.23

7.26

7.3

7.33

7.36

7.4

7.43

7.46

7.49

7.53

7.56

7.59

电池片技术

单晶硅

尺寸

182x182 mm

对角线

247±0.25 mm

电池片厚度

190 ± 30 µm

栅线宽度

0.06 mm

栅线材料

银

减反射膜

氮化硅

焊垫宽

1.8 mm

焊垫材料

银

背面电场 (BSF)

铝

峰值功率 (Pmax)

7.23 W

7.26 W

7.3 W

7.33 W

7.36 W

7.4 W

7.43 W

7.46 W

7.49 W

7.53 W

7.56 W

7.59 W

峰值工作电压 (Vmpp)

0.5703 V

0.5721 V

0.574 V

0.5757 V

0.5779 V

0.5798 V

0.5815 V

0.5834 V

0.5852 V

0.587 V

0.5889 V

0.5907 V

峰值工作电流 (Impp)

12.677 A

12.696 A

12.711 A

12.732 A

12.74 A

12.756 A

12.774 A

12.79 A

12.807 A

12.824 A

12.839 A

12.854 A

开路电压 (Voc)

0.6763 V

0.6772 V

0.6782 V

0.6783 V

0.6801 V

0.6818 V

0.6827 V

0.6836 V

0.6854 V

0.6864 V

0.6884 V

0.6904 V

短路电流 (Isc)

13.335 A

13.355 A

13.371 A

13.393 A

13.401 A

13.418 A

13.437 A

13.454 A

13.472 A

13.489 A

13.505 A

12.521 A

电池片效率

21.9-22 %

22-22.1 %

22.1-22.2 %

22.2-22.3 %

22.3-22.4 %

22.4-22.5 %

22.5-22.6 %

22.6-22.7 %

22.7-22.8 %

22.8-22.9 %

22.9-23 %

23 %

填充因子 (FF)

80.17 %

80.31 %

80.46 %

80.69 %

80.78 %

80.84 %

80.97 %

81.13 %

81.17 %

81.3 %

81.33 %

87.83 %

温度系数（Pmax）

-0.39 %/˚C

温度系数（Voc）

-0.3 %/˚C

温度系数（Isc）

0.06 %/˚C

光强相关性

光强

开路电压

峰值电压

1000 W/m²

100

800 W/m²

99.1

600 W/m²

97.84

400 W/m²

96.22

200 W/m²

93.32

下载公司产品详情

数据表

GS182M

About Us

G-STAR Pte. Ltd. is a cutting-edge high-tech enterprise that operates across the entire value chain of the solar panel industry, from producing silicon ingots and wafers to manufacturing solar cells, frames, and modules. Our expertise spans research, production, sales, and engineering technical services. Since our inception, we have adhered to a steadfast commitment to pursuing excellent quality, building a reliable brand in the photovoltaic (PV) industry. Our products undergo rigorous inspections by authoritative bodies and have garnered international recognition from entities such as ETL, TUV, and the California CEC.

At the forefront of the industry, G-STAR has implemented state-of-the-art, fully automatic component production lines and equipment. Our production technology and equipment conditions set industry standards. Our product module range encompasses varieties from 360W to 740W, including PERC, TOPCon, HJT, monofacial, bifacial, and full-black options. Widely applicable, our solar modules find use in diverse settings such as household roofs, commercial roofs, large ground power stations, and government projects. G-STAR is progressively gaining increased brand awareness in the solar photovoltaic industry.

G-STAR attaches importance to the talent development strategy, always adheres to the market orientation, and provides customers with a comprehensive service system integrating planning, design and technical guidance for undertaking large-scale power stations. With strict management measures, reliable product quality, excellent service system and low-cost control means. It has won the praise and trust of customers at home and abroad in the PV industry.

In order to jointly open up the PV market with unlimited business opportunities in the future, G-STAR will become your first choice with the best quality, the most favorable price and the best after-sales service. G-STAR always adheres to the values of "integrity, responsibility and win-win", and sincerely expects new and old customers at home and abroad to come to our company for field investigation, visit, guidance and cooperation.

Our Factory

Our Products

Projects

Exhibition

G-STAR Pte. Ltd.

: Click to show company phone
: https://www.gstarsolar.com
: 新加坡
: 60 Paya Lebar Road #06-12 Paya Lebar Square Singapore 409051

母公司： Standard Energy

联系生产商

该产品不再生产。

有用联系人

Gstar info

Lynton

Lynn

Jesse Lau

Ruben

Raj Bhaladhare

Alice

Kahn

Jay

公司描述

Gstar Solar, a proud member of Singapore-headquartered Standard Energy Group, was established in 2019 to deliver high-performance solar module solutions with global reach. Backed by strong manufacturing capabilities and a relentless focus on R&D, our 4GW module production capacity—strategically located in the Philippines and the United States—positions us to meet rising global demand for premium solar technology.

We offer a full portfolio of advanced solar modules powered by P-type, N-type, high-efficiency Back Contact (BC), and Heterojunction (HJT) cell technologies. With outputs from 100W to 740W, our products serve diverse applications—residential rooftops, commercial & industrial projects, and utility-scale installations. Trusted across North America, Europe, Asia-Pacific, and Africa, Gstar modules are engineered to exceed customer expectations through quality, performance, and adaptability.

Innovation drives our pursuit of a sustainable energy future. Beyond mainstream modules, we pioneer lightweight, portable solar solutions for outdoor, RV, yacht, and balcony applications, enhancing energy access worldwide. By fusing technical expertise with customer-centric service, Gstar empowers global decarbonization and remains committed to enabling universal access to reliable, clean energy.
