GSP7F54M/GSP7F54M(H) 390-410W

G-STAR Pte. Ltd.
类型: 背钝化 (PERC)
功率范围: 390 ~ 410 Wp
地区: 新加坡 新加坡
联系生产商
注意: 您的询盘将直接发送至G-STAR Pte. Ltd.

描述:

  • Designed to be efficient, durable, lightweight, and elegant.

  • Up to 21% peak efficiency.

  • Power range from 390 to 410 watts.

  • Half-cut PERC cells.

  • Crafted with premium materials and high-quality workmanship.

  • Certified by numerous organizations; can withstand 3600Pa snow load and 2400Pa wind load.

产品特点

产品型号
390 395 400 405 410
质量保证
产品质量保证 12 年
功率输出保证 25年期84.8%输出功率保证
电性能参数(STC)
峰值功率 (Pmax)
390 Wp 395 Wp 400 Wp 405 Wp 410 Wp
峰值工作电压(Vmpp)
30.65 V 30.85 V 31.05 V 31.24 V 31.43 V
峰值工作电流(Impp)
12.73 A 12.81 A 12.89 A 12.97 A 13.05 A
开路电压(Voc)
36.5 V 36.75 V 37 V 37.25 V 37.5 V
短路电流(Isc)
13.61 A 13.69 A 13.78 A 13.86 A 13.94 A
组件效率
20 % 20.2 % 20.5 % 20.7 % 21 %
  标准测试条件(STC):太阳能辐射通量1000W/m2,大气参数1.5,组件温度25℃。
电性能参数(NOCT)
峰值功率 (Pmax)
291 Wp 294 Wp 298 Wp 302 Wp 306 Wp
峰值工作电压(Vmpp)
28.6 V 28.8 V 29 V 29.2 V 29.3 V
峰值工作电流(Impp)
10.18 A 10.23 A 10.3 A 10.36 A 10.42 A
开路电压(Voc)
34.4 V 34.6 V 34.8 V 35.1 V 35.3 V
短路电流(Isc)
10.97 A 11.04 A 11.11 A 11.17 A 11.24 A
最大耐久温度 43±2 °C
  电池片标称工作温度(NOCT):太阳能辐射通量800W/m2,大气参数1.5,环境温度20℃,风速1 m/s。
温度特性
工作温度 -40~85 °C
温度系数(Pmax) -0.35 %/°C
温度系数(Voc) -0.26 %/°C
温度系数(Isc) 0.048 %/°C
系统集成参数
最大系统电压 1500 V
保险丝额定电流 25 A
物理参数
组件尺寸(高/宽/厚) 1722x1134x30 mm
重量 16.2 kg
电池片类型 背钝化 (PERC)
电池片数量 108
玻璃类型 防反射镀膜,钢化
玻璃厚度 2 mm
边框类型 阳极氧化铝
旁路二极管数 3
接线盒防护等级 IP 68
连接器类型 MC4
电缆截面 4 mm2
电缆长度 300 mm
PDF
下载公司产品详情

Product Details

GSP7F54M-410BB (full black solar panel) is applicable to grid connected solar system and off grid solar system. It is an efficient and high-quality product.

  • Improved module efficiency through superior manufacturing technology;

  • Five busbar technology of battery panel effectively improves temperature coefficient to avoid power loss;

  • Strict quality control to ensure that there is no small damage and other invisible defects inside the battery;

  • It can withstand 5400 Pa snow pressure and 2400 Pa wind pressure;

The products are manufactured according to the international first-class quality standards and have passed the environmental management system certification.

The surface of the product is made of low reflection and high transmittance glass, and advanced glass cutting technology is used to ensure that the product can operate efficiently in low light environment.
