UL-445~460M-108BDGN N-Type TOPConBifacial Black...

宁波尤利卡太阳能股份有限公司
技术
技术
双面, TOPCon, N型
功率范围
功率范围
445 - 460 Wp
地区
地区
中国大陆 中国大陆
重量
重量
24 kg
产品质量保证
产品质量保证
15 年
功率输出保证
功率输出保证
93.05 % 15年年限质保,87.4 % 30年年限质保
组件效率
组件效率
22.27 % - 23.02 %
组件尺寸
尺寸
1762x1134x30 mm
玻璃厚度
玻璃厚度
2.0 mm
温度系数(Pmax)
温度系数(Pmax)
-0.29 %/°C
电池片数量
电池片数量
108
价 格:
起价
¥0.752 / Wp*
*
联系生产商
注意: 您的询盘将直接发送至宁波尤利卡太阳能股份有限公司

产品特点

类型 单晶硅
产品型号
UL-445M-108BDGN UL-450M-108BDGN UL-455M-108BDGN UL-460M-108BDGN

产品质量保证 15 年
功率输出保证 93.05 % 15年年限质保,87.4 % 30年年限质保
0.42 %
功率偏差 0 ~ +1 %
电性能参数(STC)
峰值功率 (Pmax)
445 Wp 450 Wp 455 Wp 460 Wp
峰值工作电压(Vmpp)
33.02 V 33.22 V 33.42 V 33.63 V
峰值工作电流(Impp)
13.48 A 13.55 A 13.61 A 13.68 A
开路电压(Voc)
39.58 V 39.78 V 39.98 V 40.18 V
短路电流(Isc)
14.3 A 14.38 A 14.45 A 14.46 A
组件效率
22.27 % 22.52 % 22.77 % 23.02 %
电性能参数(NOCT)
峰值功率 (Pmax)
337 Wp 341 Wp 345 Wp 349 Wp
峰值工作电压(Vmpp)
30.38 V 30.56 V 30.75 V 30.94 V
峰值工作电流(Impp)
11.1 A 11.16 A 11.21 A 11.27 A
开路电压(Voc)
36.02 V 36.2 V 36.38 V 36.56 V
短路电流(Isc)
11.53 A 11.6 A 11.65 A 11.66 A
最大耐久温度 43±2 °C

工作温度 -40 - 85 °C
温度系数(Pmax) -0.29 %/°C
温度系数(Voc) -0.25 %/°C
温度系数(Isc) 0.046 %/°C

最大系统电压 1500 V
保险丝额定电流 30 A

组件尺寸(高/宽/厚) 1762x1134x30 mm
重量 24 kg
电池片规格 182.2×94 mm
电池片数量 108
玻璃类型 防反射镀膜,钢化
玻璃厚度 2.0 mm
密封材料类型 EVA
边框类型 阳极氧化铝
旁路二极管数 3
接线盒防护等级 IP 68
连接器类型 MC4
电缆截面 4 mm2
电缆长度 1100 mm

下载公司产品详情

宁波尤利卡太阳能股份有限公司

Click to show company phone
www.ulicasolar.com
中国大陆
浙江省宁波市海曙区云林中路238号A1座
员工数: 500
母公司: SC Energy
注意: 您的询盘将直接发送至宁波尤利卡太阳能股份有限公司

晶体硅

产量 (MW)/: MWp
单晶硅,多晶硅
功 率 范 围(Wp): 360-725
公司描述

Established in August 2005, Ningbo Ulica Solar Co.,Ltd. is a vertically fully integrated manufacturer of solar wafer, solar cells and solar modules in China. With strong R&D team originated from Top university in China, Ulica Solar is the first manufacturer in PV industry who has launched solar modules with innovative cutting free cell technology and global patented stacked-finger technology, with no cutting power loss and low micro cracks and stable performance.

产品视频
产品

Technology & Equipment

We are cooperating with some of the world-famous equipment suppliers, such as Centrotherm, Baccini and Gorosabel, which are all the top-ranking global suppliers of PV equipment. We have brought in the most advanced and brand-new equipment from them.

The business partnership with these famous suppliers is the prerequisite for us to provide high-quality products.

As the leaders in PV equipment, our suppliers have many years of experience in this industry and enjoy a very high global reputation. Their websites are as follows:

Quality & Certificates

We attach much importance to the quality of our products. With the quality policy of client satisfaction, quality first, technological innovation and pursuit of better, we make quality assurance and improvements throughout the whole production process and have won wide praise among our clients. Generally, there are two items, namely quality prevention and quality inspection, for quality control. To assure quality, the quality control procedure is composed of Incoming Quality Control, In-process Quality Control, Quality control for Semi-products, Final Quality Control, Outgoing Quality Control, and Quality Audit.

We have obtained many important international certificates, such as CE, IEC61215 & 61730/TüV, UL, ISO9001, etc. Our quality concept is that good quality is the only way out of business survival and development. With continuous quality improvements and the participation of all the staff, we do our utmost to make our quality among the best in this industry. About Solar module certifications, please click to download.

Reference Projects

Ulica's modules have been applied in a wide range of applications including large-scale ground-based systems, roof systems, BIPV systems and others, both on-grid and off-grid.

Ulica's modules have been applied in a wide range of applications including large-scale ground-based systems, roof systems, BIPV systems and others, both on-grid and off-grid.
