PYTES 12V 100Ah Energy Storage Battery

上海派智能源股份有限公司
标称容量
标称容量
100 Ah
标称电压
标称电压
12 V
技术
技术
LFP(磷酸锂铁)
地区
地区
中国大陆 中国大陆
重量
重量
15.2 kg
产品质量保证
产品质量保证
5 年
循环寿命
循环寿命
4000@80%DOD
设计寿命
设计寿命
5 年
配置
配置
仅电池
最大放电电流
最大放电电流
100 A
联系生产商
注意: 您的询盘将直接发送至上海派智能源股份有限公司

Warehouses in the Netherlands and USA

Price Term EXW Shanghai

Max support 15 units in parallel

LFP battery cells, self-designed BMS and 18 Years battery structure design experience

≥6000 cycles

Accessories included support wall-mounting or ground-mounting

COmpatible with as many as 16 hybrid inverters

10 Years Global Warranty

仓库:
西雅图 美国
库存量:
56 件
安大略 美国
库存量:
90 件
德克萨斯城 美国
库存量:
40 件
瓦伦西亚 西班牙
库存量:
40 件
斯海恩德尔 荷兰
库存量:
48 件
仓库地点: 西雅图 美国
型号 库存量(件) 联系生产商
E-Box-12100 56
仓库地点: 安大略 美国
型号 库存量(件) 联系生产商
E-Box-12100 90
仓库地点: 德克萨斯城 美国
型号 库存量(件) 联系生产商
E-Box-12100 40
仓库地点: 瓦伦西亚 西班牙
型号 库存量(件) 联系生产商
E-Box-12100 40
仓库地点: 斯海恩德尔 荷兰
型号 库存量(件) 联系生产商
E-Box-12100 48

产品特点

产品型号
E-Box-12100
产品质量保证 (最低) 5 年
配置 仅电池
储能系统技术 LFP(磷酸锂铁)
部件 电池管理系统
安装方式 地板
最大并行单元数 16


标称电压
12 V
工作电压范围 10.8 - 14.4 V
标称容量
100Ah@20hr
标称放电电流
50 A
标称充电电流
100 A
最大放电电流
100 A
最大充电电流
50 A
设计寿命
5 年
循环寿命 4000@80%DOD

工作温度范围 -10 ~ +55 ℃

尺寸(长*宽*高)
320x166x200 mm
重量
15.2 Kg
IP 等级 IP20
冷却方式 自然冷却
通信 CAN, RS485

Product Summary

[Deep Cycle Lithium Battery]

High-quality, advanced lithium iron phosphate batteries offer up to 6,000 cycles, helping you save money by eliminating the need for frequent replacements. Thanks to their low self-discharge rate, LiFePO4 batteries remain fully functional even after a year of storage. With no memory effect, they can be recharged at any state of charge without compromising performance.

[Scalable and Versatile]

For increased capacity and higher voltage, the auto-balancing feature ensures safe parallel connection of batteries without internal imbalance issues. The PYTES E-BOX 12100 deep-cycle lithium-ion battery is widely used in RVs, campers, marine applications, backup power systems, and off-grid solutions.

[Battery Management System]

The PYTES E-BOX 12100 LiFePO4 battery comes with a built-in Battery Management System (BMS) that monitors battery temperature. The BMS protects against short circuits, overcharging, over-discharging, over-current, over-voltage, and under-voltage. Weighing only one-third of lead-acid batteries with equivalent capacity, PYTES lithium batteries are easy to carry and use in outdoor settings. Our LiFePO4 batteries are made from non-toxic materials and are completely environmentally friendly.

[High-Efficiency Battery]

With 1C continuous discharge and 2C peak discharge capabilities, these batteries deliver reliable and high-performance power output.

上海派智能源股份有限公司

Click to show company phone
https://www.pytesgroup.com
中国大陆
上海市奉贤区金钱公路3492号
员工数: 1,000
注意: 您的询盘将直接发送至上海派智能源股份有限公司

有用联系人

公司描述

As a leading lithium battery solution provider, Pytes is committed to providing energy storage solutions. Started in 2004, with continuous support and technical experience, more than 1,000 Pytes employees are now working to build a greener future.

Grasping the general trend of globalization, Pytes not only has multiple production bases in China, but also runs branches, offices and factories in North America, Europe, Vietnam and other sites to achieve multi-regional coverage of the service network, with faster delivery and quicker response.

Creating, Undertaking, Sharing, we practice our philosophy and fulfill the mission that to deliver safe, reliable and affordable clean energy to home and community for a more carbon-free future.
