Panda Single-Phase Series residential energy st...

Zonergy Corporation
标称容量
标称容量
100 Ah
标称电压
标称电压
51.2 V
技术
技术
LFP(磷酸锂铁)
地区
地区
中国大陆 中国大陆
产品质量保证
产品质量保证
10 年
设计寿命
设计寿命
10 年
配置
配置
堆叠式
价 格:
起价
¥1,280 / kWh*
*
每件价格
每件价格
最低订购量 1-1999 2000-3999 4000+
交货时间 7 days 71 days 71 days
Panda 3680S-5HP ¥8,210 ¥7,390 ¥6,570
Panda 5000S-5HP ¥8,210 ¥7,390 ¥6,570
Panda 6000S-5HP ¥8,210 ¥7,390 ¥6,570
联系生产商
注意: 您的询盘将直接发送至Zonergy Corporation
  • The 5 KWh module adopted enables a variable capacity range of 5-30 kWh

  • The switching time between the on-off grid is less than 10 ms, which secures an uninterruptable power supply for the load

  • The Lithium Iron Phosphate (LFP) cell secures safe and reliable operation

产品特点

产品型号
Panda 3680S-5HP Panda 5000S-5HP Panda 6000S-5HP
价格( kWh)
¥1,280 / kWh * ¥1,280 / kWh * ¥1,280 / kWh *
价格( 台)
¥6,570 / 台 * ¥6,570 / 台 * ¥6,570 / 台 *
产品质量保证 (最低) 10 年
配置 堆叠式
储能系统技术 LFP(磷酸锂铁)
部件 inverter
安装方式 地板


标称电压
51.2 V 51.2 V 51.2 V
工作电压范围 180 - 276 V
标称容量
100Ah@20hr 100Ah@20hr 100Ah@20hr
标称能量
5.12 kWh 5.12 kWh 5.12 kWh
可用能量
4.6 kWh 4.6 kWh 4.6 kWh
设计寿命
10 年 10 年 10 年

工作温度范围 -20 ~ +50 ℃

尺寸(长*宽*高)
650x620x180 mm 650x620x180 mm 650x620x180 mm
IP 等级 IP65
通信 CAN, RS485, WiFi
监控 屏幕


最大输入功率
6 kW 7.5 kW 9 kW
最大输入电压
600 V 600 V 600 V
最小输入电压
120 V 120 V 120 V
标称输入电流
13 A 13 A 13 A
MPP(T)电压范围
100~550 V 100~550 V 100~550 V
MPPT数量
2 2 2

最大输出功率
4 kW 5 kW 6 kW
交流电压范围
180~276 V 180~276 V 180~276 V
标称交流电压
220, 230, 240 V 220, 230, 240 V 220, 230, 240 V
频率
50, 60 Hz 50, 60 Hz 50, 60 Hz
相数
1 1 1

尺寸(高/宽/厚)
540x450x185 mm 540x450x185 mm 540x450x185 mm
防护等级 IP65
散热方式 自然冷却
通讯接口 RS 485
显示屏 LCD
