AS Mini-rail Kit Trapezoidal Metal Roof

厦门元聚荣能源科技有限公司
价 格:
起价 ¥0.12 / Wp
起价 ¥480 / 10 块组件
地区: 中国大陆 中国大陆
联系生产商
注意: 您的询盘将直接发送至厦门元聚荣能源科技有限公司

描述:

  • Suitable for any trapezoid roof mounting configurations;

  • U rail fasten clamp ensures simple and easy solar panel mounting on metal roofs;

  • Optional pre-assembling service for added convenience;

  • Anti-corrosion, waterproof structure for enhanced durability;

  • No welding / cutting required during installation.

产品特点

产品型号
AS Tin Roof Railless Short Rail Bracket
产品质量保证 10 年
系统概述
类型 斜面屋顶
支架系统排列方式 按行排
组件边框 有边框,无边框
组件排列方向 纵向,横向
屋面类型 焊缝金属,箔,钢,铝
倾斜角度
0-15 °
风荷载
216 km/h
雪荷载
1.6 kN/m2
一般参数
轨道材质 铝,不锈钢
零部件材质 铝,不锈钢
PDF
下载公司产品详情

AS Mini-rail Kit Trapezoidal Metal Roof

AS Mini-rail Kit Trapezoidal Metal Roof Solar Mounting System is designed for solar installation on trapezoidal color steel metal roof. With mini-rail design, the system still delivers firm and stable fixation between metal roof and solar. As a cost-effective mounting solution, the mini-rail kit greatly reduces overall project cost.

Advantages

Thanks to the wide range and modular structure of our pitched roof racking system, we can build a solar power plant on almost every sloping roof, using all the PV modules currently on the market. Angels Solar mounting solutions are extremely durable, have high load capacity, are fast to install, and therefore cost effective.

Design

It is necessary for us to design and quote

1. Solar panel info. Dinesion L_____ mm W_____ mm T_____ mm ; Power _____ watt/panel Qty. _____ pcs

2. _____ m/s wind speed and _____ KN/m2 snow load

3. Tilt angle _____ deg. (Or E °/ W °)

4. Array layout : _____ Nos. in a row × _____ Nos. in a column

Specification

Product

AS Mini Rail Kit U Shape Railless Short Rail Trapezoidal Metal Roof

Application

Pitched Roof

Roof Type

Trapezoidal Metal Roof

Tilt Angle

0°to 45°

Wind Speed

60 m/s

Snow Load

1.4 KN/m²

Solar Panel

Framed and Frameless

Panel Layout

Portrait or Landscape

Design Standard

AS / NZS 1170 ,DIN 1055 ,JIS C8955 :2017 ,International Building Code IBC 2009

Material

Structure: Al6005-T5(Anodized) Components: SUS304 & Al6005-T5(Anodized)

About Angels Solar

Xiamen Angels Solar Energy Co., Ltd specializes in designing, manufacturing, and promoting solar mounting systems.

With our mother company having over 10 years of experience in ODM and manufacturing galvanized steel and aluminum structures, our expertise in metallic structures and raw materials supply chain management, as well as quality inspection and control, makes Angels Solar competitive in delivering cost-effective and solid solar mounting solutions and products.

With a dedicated and experienced R&D engineering team and an efficient supply chain, we have launched a series of solar mounting systems covering residential, commercial, and utility applications. We are determined to become an all-round solar mounting solution and product provider. 'Quality, Value, Service' is the principle we pursue. We deliver the value of mounting structures in solar projects through innovation in product design and satisfy our customers by providing professional service throughout the entire process of project planning, design, delivery, and commissioning.

Together with our customers, suppliers, and fellow companies, we look forward to building a society of sustainable development and a greener future.
