WR7-72HVD 640~665M

上海蔚然光电股份有限公司
技术
双面, 背接触式
功率范围
640 - 665 Wp
地区
中国大陆 中国大陆
重量
33.5 kg
产品质量保证
15 年
功率输出保证
99 % 1年年限质保,88.85 % 30年年限质保
组件效率
23.7 % - 24.6 %
尺寸
2382x1134x30 mm
玻璃厚度
2 mm
温度系数(Pmax)
-0.26 %/°C
电池片数量
144
联系生产商
注意: 您的询盘将直接发送至上海蔚然光电股份有限公司
  • Suitable for the Distribution Market

  • Peak Efficiency with Top Power Generation Performance

  • Tairay Wafer & BC Technology Enhances High Product Reliability

  • Suitable for Industrial/Commercial Cement Roofs & High-Temperature Scenarios

产品特点

类型 单晶硅
产品型号
WR7-72HVD-640M WR7-72HVD-645M WR7-72HVD-650M WR7-72HVD-655M WR7-72HVD-660M WR7-72HVD-665M

产品质量保证 15 年
功率输出保证 99 % 1年年限质保,88.85 % 30年年限质保
0.37 %
功率偏差 0 ~ +3 %
电性能参数(STC)
峰值功率 (Pmax)
640 Wp 645 Wp 650 Wp 655 Wp 660 Wp 665 Wp
峰值工作电压(Vmpp)
44.67 V 44.77 V 44.87 V 44.97 V 45.07 V 45.17 V
峰值工作电流(Impp)
14.33 A 14.41 A 14.49 A 14.57 A 14.65 A 14.72 A
开路电压(Voc)
54.02 V 54.12 V 54.22 V 54.32 V 54.42 V 54.52 V
短路电流(Isc)
14.98 A 15.06 A 15.14 A 15.22 A 15.3 A 15.35 A
组件效率
23.7 % 23.9 % 24.1 % 24.2 % 24.4 % 24.6 %
电性能参数(NOCT)
峰值功率 (Pmax)
487 Wp 491 Wp 495 Wp 499 Wp 502 Wp 506 Wp
峰值工作电压(Vmpp)
42.45 V 42.55 V 42.64 V 42.74 V 42.83 V 42.93 V
峰值工作电流(Impp)
11.49 A 11.55 A 11.61 A 11.68 A 11.75 A 11.8 A
开路电压(Voc)
51.34 V 51.43 V 51.53 V 51.62 V 51.72 V 51.81 V
短路电流(Isc)
12.03 A 12.1 A 12.16 A 12.22 A 12.29 A 12.33 A
最大耐久温度 45±2 °C

工作温度 -40 - 85 °C
温度系数(Pmax) -0.26 %/°C
温度系数(Voc) -0.2 %/°C
温度系数(Isc) 0.05 %/°C

最大系统电压 1500 V
保险丝额定电流 30 A

组件尺寸(高/宽/厚) 2382x1134x30 mm
重量 33.5 kg
电池片数量 144
玻璃类型 钢化
玻璃厚度 2 mm
边框类型 阳极氧化铝
旁路二极管数 3
接线盒防护等级 IP 68
电缆截面 4 mm2

下载公司产品详情
