LR7-72HVHF 640~670M

上海蔚然光电股份有限公司
功率范围
640 - 670 Wp
地区
中国大陆 中国大陆
重量
28.5 kg
产品质量保证
15 年
功率输出保证
99 % 1年年限质保,88.85 % 30年年限质保
组件效率
23.7 % - 24.8 %
尺寸
2382x1134x30 mm
玻璃厚度
3.2 mm
温度系数(Pmax)
-0.260 %/°C
电池片数量
144
价 格:
起价
¥0.644 / Wp*
*
每件价格
每件价格
最低订购量 36+
交货时间 5 days
LR7-72HVHF-640M ¥412
LR7-72HVHF-645M ¥446
LR7-72HVHF-650M ¥453
LR7-72HVHF-655M ¥453
LR7-72HVHF-660M ¥460
LR7-72HVHF-665M ¥460
LR7-72HVHF-670M ¥467
联系生产商
注意: 您的询盘将直接发送至上海蔚然光电股份有限公司

产品特点

类型 单晶硅
产品型号
LR7-72HVHF-640M LR7-72HVHF-645M LR7-72HVHF-650M LR7-72HVHF-655M LR7-72HVHF-660M LR7-72HVHF-665M LR7-72HVHF-670M

产品质量保证 15 年
功率输出保证 99 % 1年年限质保,88.85 % 30年年限质保
0.37 %
功率偏差 -3 ~ +3 %
电性能参数(STC)
峰值功率 (Pmax)
640 Wp 645 Wp 650 Wp 655 Wp 660 Wp 665 Wp 670 Wp
峰值工作电压(Vmpp)
44.36 V 44.46 V 44.56 V 44.66 V 44.76 V 44.86 V 44.96 V
峰值工作电流(Impp)
14.43 A 14.51 A 14.59 A 14.67 A 14.75 A 14.83 A 14.91 A
开路电压(Voc)
53.7 V 53.8 V 53.9 V 54 V 54.1 V 54.2 V 54.3 V
短路电流(Isc)
15.13 A 15.21 A 15.29 A 15.37 A 15.45 A 15.52 A 15.6 A
组件效率
23.7 % 23.9 % 24.1 % 24.2 % 24.4 % 24.6 % 24.8 %
电性能参数(NOCT)
峰值功率 (Pmax)
487 Wp 491 Wp 495 Wp 499 Wp 502 Wp 506 Wp 510 Wp
峰值工作电压(Vmpp)
42.15 V 42.25 V 42.35 V 42.44 V 42.54 V 42.63 V 42.73 V
峰值工作电流(Impp)
11.56 A 11.63 A 11.69 A 11.76 A 11.82 A 11.88 A 11.94 A
开路电压(Voc)
51.04 V 51.13 V 51.23 V 51.32 V 51.42 V 51.51 V 51.61 V
短路电流(Isc)
12.15 A 12.22 A 12.28 A 12.34 A 12.41 A 12.47 A 12.53 A

工作温度 -40 - 85 °C
温度系数(Pmax) -0.260 %/°C
温度系数(Voc) -0.260 %/°C
温度系数(Isc) +0.050 %/°C

最大系统电压 1500 V
保险丝额定电流 25 A

组件尺寸(高/宽/厚) 2382x1134x30 mm
重量 28.5 kg
电池片规格 24×6 mm
电池片数量 144
玻璃厚度 3.2 mm

下载公司产品详情

上海蔚然光电股份有限公司

Click to show company phone
https://www.weransolar.com
中国大陆
201106 上海市闵行区申虹路666弄正荣中心南区3号楼503室
员工数: 150
注意: 您的询盘将直接发送至上海蔚然光电股份有限公司

晶体硅

产量 (MW)/: MWp
单晶硅
功 率 范 围(Wp): 420-670
公司描述

威然太阳能有限公司(WERAN)成立于2015年,是一家专业从事太阳能智能发电系统的新兴能源企业。我们集产品设计、制造、销售、安装及设备维护于一体。核心服务包括光伏组件制造、国际贸易、新能源项目EPC总承包以及新能源汽车充电站投资。威然还率先推出“农光互补”和“工商业光伏协同”等创新解决方案。公司在中国各地设有子公司,并在全球范围内拓展业务,致力于推动新能源领域的发展,促进城市建设,推动综合产业解决方案的实施。

产品

LONGi Hi-MO 7 LR5-78HGD 615–645M

Built on advanced HPDC cell technology, the LONGi Hi-MO 7 module delivers outstanding efficiency and long-term reliability for distributed solar projects. With a maximum power output of up to 645W and module efficiency reaching 23.1%, it provides higher energy yield and stronger return on investment.

Featuring half-cell design, low temperature coefficient, and optimized power degradation performance, Hi-MO 7 ensures stable power generation even under challenging environmental conditions. The module is backed by 12-year product warranty and 30-year linear power output guarantee, ensuring dependable performance throughout its lifecycle.

A high-performance solution designed to maximize system value, reduce LCOE, and deliver consistent energy generation over decades.

LONGi Hi-MO X10 Scientist LR7-72HVD 640–665M

Built with advanced TaiRay wafer and BC cell technology, the LONGi Hi-MO X10 module delivers exceptional efficiency, reliability, and power generation performance for modern solar installations. With a power output of up to 665W and maximum module efficiency reaching 24.6%, it provides outstanding energy yield and improved project returns.

Designed for demanding environments, Hi-MO X10 offers lower operating temperature and enhanced stability, making it particularly suitable for industrial and commercial rooftop systems and high-temperature regions. Backed by a 15-year product warranty and a 30-year linear power output warranty, it ensures long-term reliability and consistent performance across its entire lifecycle.

A premium high-efficiency module engineered to reduce LCOE, maximize system value, and deliver stable energy generation for decades.

LONGi Hi-MO 7 LR8-66HGD 620W

The LR8-66HGD 620W module is a high-performance bifacial solar solution designed for utility-scale and large commercial PV projects. Powered by advanced HPDC cell technology and a half-cell design, it delivers a rated output of 620W with up to 23.0% module efficiency, enabling higher energy yield per unit area.

With 0–3% positive power tolerance, less than 1% first-year degradation, and a low 0.4% annual degradation from year 2 to year 30, the module ensures stable and predictable long-term performance. Its high bifacial factor of 80% ±5%, combined with an excellent temperature coefficient (-0.28%/°C), provides significant additional energy gain under high irradiance and reflective ground conditions.

The robust double-glass structure, high mechanical load capacity (5400Pa front / 2400Pa rear), and IP68-rated junction box enhance durability in harsh environments. Backed by a 12-year product warranty and an industry-leading 30-year linear power output warranty, the LR8-66HGD 620W is a reliable choice for projects seeking long-term value and maximum returns.
