Longi Solar LR5-54HTH 420~440M

上海蔚然光电股份有限公司
技术
背接触式, N型
功率范围
420 - 440 Wp
地区
中国大陆 中国大陆
重量
20.8 kg
产品质量保证
15 年
功率输出保证
98.5 % 1年年限质保,88.9 % 25年年限质保
组件效率
21.5 % - 22.5 %
尺寸
1722x1134x30 mm
玻璃厚度
3.2 mm
温度系数(Pmax)
-0.29 %/°C
电池片数量
108
价 格:
起价
¥0.517 / Wp*
*
每件价格
每件价格
最低订购量 36+
交货时间 5 days
WR5-54HTH-420M ¥218
WR5-54HTH-425M ¥220
WR5-54HTH-430M ¥223
WR5-54HTH-435M ¥234
WR5-54HTH-440M ¥238
联系生产商
注意: 您的询盘将直接发送至上海蔚然光电股份有限公司
  • Suitable for the Distribution Market

  • HPBC Cell and Tairay Inside, Provide Stronger Power Generation Performance

  • Optimum Size-Lower Transportation Costs and BOS Costs

  • Full Back Welding Technology Enhances Panel's Resistance to Micro-cracking

  • No Grid Line On the Front Surface

产品特点

类型 单晶硅
产品型号
WR5-54HTH-420M WR5-54HTH-425M WR5-54HTH-430M WR5-54HTH-435M WR5-54HTH-440M

产品质量保证 15 年
功率输出保证 98.5 % 1年年限质保,88.9 % 25年年限质保
0.44 %
功率偏差 0 ~ +3 %
电性能参数(STC)
峰值功率 (Pmax)
420 Wp 425 Wp 430 Wp 435 Wp 440 Wp
峰值工作电压(Vmpp)
32.44 V 32.64 V 32.84 V 33.04 V 33.24 V
峰值工作电流(Impp)
12.95 A 13.03 A 13.1 A 13.17 A 13.24 A
开路电压(Voc)
38.73 V 38.93 V 39.13 V 39.33 V 39.53 V
短路电流(Isc)
14 A 14.07 A 14.15 A 14.22 A 14.3 A
组件效率
21.5 % 21.8 % 22 % 22.3 % 22.5 %
电性能参数(NOCT)
峰值功率 (Pmax)
314 Wp 318 Wp 321 Wp 325 Wp 329 Wp
峰值工作电压(Vmpp)
29.6 V 29.78 V 29.97 V 30.15 V 30.33 V
峰值工作电流(Impp)
10.6 A 10.67 A 10.72 A 10.78 A 10.85 A
开路电压(Voc)
36.36 V 36.55 V 36.74 V 36.93 V 37.11 V
短路电流(Isc)
11.31 A 11.36 A 11.43 A 11.49 A 11.55 A
最大耐久温度 45±2 °C

工作温度 -40 - 85 °C
温度系数(Pmax) -0.29 %/°C
温度系数(Voc) -0.23 %/°C
温度系数(Isc) 0.05 %/°C

最大系统电压 1500 V
保险丝额定电流 25 A

组件尺寸(高/宽/厚) 1722x1134x30 mm
重量 20.8 kg
电池片数量 108
玻璃类型 钢化
玻璃厚度 3.2 mm
边框类型 阳极氧化铝,黑色
接线盒防护等级 IP 68
电缆截面 4 mm2
电缆长度 1200 mm

下载公司产品详情

上海蔚然光电股份有限公司

Click to show company phone
https://www.weransolar.com
中国大陆
201106 上海市闵行区申虹路666弄正荣中心南区3号楼503室
员工数: 150
注意: 您的询盘将直接发送至上海蔚然光电股份有限公司

晶体硅

产量 (MW)/: MWp
单晶硅
功 率 范 围(Wp): 420-670
公司描述

威然太阳能有限公司(WERAN)成立于2015年,是一家专业从事太阳能智能发电系统的新兴能源企业。我们集产品设计、制造、销售、安装及设备维护于一体。核心服务包括光伏组件制造、国际贸易、新能源项目EPC总承包以及新能源汽车充电站投资。威然还率先推出“农光互补”和“工商业光伏协同”等创新解决方案。公司在中国各地设有子公司,并在全球范围内拓展业务,致力于推动新能源领域的发展,促进城市建设,推动综合产业解决方案的实施。

产品

LONGi Hi-MO X10 LR7-72HVD 640–665M

Built with advanced TaiRay wafer and BC cell technology, the LONGi Hi-MO X10 module delivers exceptional efficiency, reliability, and power generation performance for modern solar installations. With a power output of up to 665W and maximum module efficiency reaching 24.6%, it provides outstanding energy yield and improved project returns.

Designed for demanding environments, Hi-MO X10 offers lower operating temperature and enhanced stability, making it particularly suitable for industrial and commercial rooftop systems and high-temperature regions. Backed by a 15-year product warranty and a 30-year linear power output warranty, it ensures long-term reliability and consistent performance across its entire lifecycle.

A premium high-efficiency module engineered to reduce LCOE, maximize system value, and deliver stable energy generation for decades.

LONGi Hi-MO 7 LR8-66HGD 620W

The LR8-66HGD 620W module is a high-performance bifacial solar solution designed for utility-scale and large commercial PV projects. Powered by advanced HPDC cell technology and a half-cell design, it delivers a rated output of 620W with up to 23.0% module efficiency, enabling higher energy yield per unit area.

With 0–3% positive power tolerance, less than 1% first-year degradation, and a low 0.4% annual degradation from year 2 to year 30, the module ensures stable and predictable long-term performance. Its high bifacial factor of 80% ±5%, combined with an excellent temperature coefficient (-0.28%/°C), provides significant additional energy gain under high irradiance and reflective ground conditions.

The robust double-glass structure, high mechanical load capacity (5400Pa front / 2400Pa rear), and IP68-rated junction box enhance durability in harsh environments. Backed by a 12-year product warranty and an industry-leading 30-year linear power output warranty, the LR8-66HGD 620W is a reliable choice for projects seeking long-term value and maximum returns.
