Vertical Energy Storage System

天辰尚能科技(深圳)有限公司
标称容量
标称容量
100 ~ 400 Ah
标称电压
标称电压
25.6 ~ 51.2 V
技术
技术
LFP(磷酸锂铁)
地区
地区
中国大陆 中国大陆
重量
重量
68 ~ 178 kg
设计寿命
设计寿命
15 年
配置
配置
一体机
联系生产商
注意: 您的询盘将直接发送至天辰尚能科技(深圳)有限公司
  • Long Lifespan: 15years of design service life

  • Modular design: simple and fast

  • Intelligentize: Efficient operation and maintenance

  • Multi-parallel use: Hybrid grid inverter, supports parallel

  • Visualization: Visual display interface, easy to maintain

  • Multifunction: Support RS485/RS232 wireless network

产品特点

产品型号
Merak-3K-5 Merak-3K-10 Merak-5K-5 Merak-5K-10 Merak-5K-15 Merak-10K-10 Merak-10K-15
配置 一体机
储能系统技术 LFP(磷酸锂铁)
部件 inverter
安装方式 地板


标称电压
25.6 V 25.6 V 51.2 V 51.2 V 51.2 V 51.2 V 51.2 V
标称容量
200Ah@20hr 400Ah@20hr 100Ah@20hr 200Ah@20hr 300Ah@20hr 200Ah@20hr 300Ah@20hr
标称能量
5.12 kWh 10.24 kWh 5.12 kWh 10.24 kWh 15.36 kWh 10.24 kWh 15.36 kWh
设计寿命
15 年 15 年 15 年 15 年 15 年 15 年 15 年

尺寸(长*宽*高)
200x598x794 mm 200x598x1224 mm 200x598x764 mm 200x598x1224 mm 200x598x1654 mm 200x600x1342 mm 200x600x1772 mm
重量
68 Kg 118 Kg 68 Kg 118 Kg 168 Kg 128 Kg 178 Kg
IP 等级 IP20
最高运行海拔 4000 m
通信 RS232, RS485, WiFi
监控 屏幕

下载公司产品详情

Our Products

Our Factory

Our Certifications

天辰尚能科技(深圳)有限公司

Click to show company phone
https://www.tcsnpower.com
中国大陆
广东省深圳市前海深港合作区南山街道自贸西街18号前海香缤大厦1011
注意: 您的询盘将直接发送至天辰尚能科技(深圳)有限公司
公司描述

TCSN Power Technology (Shenzhen) Co., Ltd is a high-tech enterprise focused on the research, development, manufacturing, and production of lithium-ion batteries and their systems. The company specialises in producing prismatic lithium iron phosphate batteries known for their high charge/discharge rates and long cycle life. These batteries and associated systems are widely used in energy storage, uninterruptible power supplies (UPS) for data centres, specialised power applications, communications, and various other sectors.

Headquartered in Shanghai, the company has two production facilities in Huizhou and two sales centres located in Shenzhen and Sydney. With substantial research, development, and manufacturing capabilities, the company specialises in battery cells, battery management systems (BMS), lithium-ion battery systems, and inverter technology.

TCSN Power Technology (Shenzhen) Co., Ltd holds multiple management system certifications, including ISO9001, ISO14001, and ISO45001. Its products have successfully passed various certifications, such as UL, FCC, CE, CB, UN, RoHS, and REACH. The company possesses over 30 patents and has significant experience in the renewable energy industry.

TCSN's products are highly reliable, designed for high charge/discharge rates, and take into account both quality and cost-effectiveness. They have received positive feedback from both domestic and international markets.
