Low-Voltage UPS System Lead-Acid Replacement Se...

天辰尚能科技(深圳)有限公司
标称容量
标称容量
6 ~ 18 Ah
标称电压
标称电压
12.8 V
技术
技术
LFP(磷酸锂铁)
地区
地区
中国大陆 中国大陆
重量
重量
0.6 ~ 2.0 kg
配置
配置
仅电池
最大放电电流
最大放电电流
18 ~ 40 A
价 格:
起价
¥874 / kWh*
*
每件价格
每件价格
最低订购量 50-99 100-199 200+
交货时间 10 days 10 days 10 days
S12-6 ¥86.9 ¥85.2 ¥84.3
S12-8 ¥106 ¥104 ¥103
S12-9 ¥119 ¥117 ¥116
S12-12 ¥155 ¥152 ¥150
S12-18 ¥232 ¥228 ¥225
E12-6 ¥69.2 ¥67.8 ¥67.2
E12-8 ¥96.1 ¥94.2 ¥93.2
E12-9 ¥105 ¥102 ¥101
E12-12 ¥139 ¥136 ¥135
E12-18 ¥209 ¥205 ¥203
联系生产商
注意: 您的询盘将直接发送至天辰尚能科技(深圳)有限公司
  • Long Life Cycle

  • Light in Weight

  • High Cycling Utilization

  • Multi-String Configuration

  • Easy Maintenance

  • Enhanced Safety

产品特点

产品型号
S12-6 S12-8 S12-9 S12-12 S12-18 E12-6 E12-8 E12-9 E12-12 E12-18
价格( kWh)
¥1,100 / kWh * ¥1,000 / kWh * ¥1,010 / kWh * ¥977 / kWh * ¥979 / kWh * ¥874 / kWh * ¥910 / kWh * ¥880 / kWh * ¥879 / kWh * ¥880 / kWh *
价格( 台)
¥84.3 / 台 * ¥103 / 台 * ¥116 / 台 * ¥150 / 台 * ¥225 / 台 * ¥67.2 / 台 * ¥93.2 / 台 * ¥101 / 台 * ¥135 / 台 * ¥203 / 台 *
配置 仅电池
储能系统技术 LFP(磷酸锂铁)
部件 电池管理系统
安装方式 机架
最大并行单元数 100


标称电压
12.8 V 12.8 V 12.8 V 12.8 V 12.8 V 12.8 V 12.8 V 12.8 V 12.8 V 12.8 V
标称容量
6Ah@20hr 8Ah@20hr 9Ah@20hr 12Ah@20hr 18Ah@20hr 6Ah@20hr 8Ah@20hr 9Ah@20hr 12Ah@20hr 18Ah@20hr
最大放电电流
18 A 20 A 27 A 20 A 40 A 18 A 20 A 27 A 20 A 40 A

尺寸(长*宽*高)
70x90x100 mm 65x151x100 mm 65x151x100 mm 65x151x100 mm 77x181x167 mm 70x90x100 mm 65x151x100 mm 65x151x100 mm 65x151x100 mm 77x181x167 mm
重量
0.6 Kg 1.1 Kg 1.3 Kg 1.4 Kg 2.0 Kg 1.1 Kg 1.3 Kg 1.4 Kg 2.0 Kg
IP 等级 IP67
冷却方式 自然冷却

下载公司产品详情

Our Products

Our Factory

Our Certifications

天辰尚能科技(深圳)有限公司

Click to show company phone
https://www.tcsnpower.com
中国大陆
广东省深圳市前海深港合作区南山街道自贸西街18号前海香缤大厦1011
注意: 您的询盘将直接发送至天辰尚能科技(深圳)有限公司
公司描述

TCSN Power Technology (Shenzhen) Co., Ltd is a high-tech enterprise focused on the research, development, manufacturing, and production of lithium-ion batteries and their systems. The company specialises in producing prismatic lithium iron phosphate batteries known for their high charge/discharge rates and long cycle life. These batteries and associated systems are widely used in energy storage, uninterruptible power supplies (UPS) for data centres, specialised power applications, communications, and various other sectors.

Headquartered in Shanghai, the company has two production facilities in Huizhou and two sales centres located in Shenzhen and Sydney. With substantial research, development, and manufacturing capabilities, the company specialises in battery cells, battery management systems (BMS), lithium-ion battery systems, and inverter technology.

TCSN Power Technology (Shenzhen) Co., Ltd holds multiple management system certifications, including ISO9001, ISO14001, and ISO45001. Its products have successfully passed various certifications, such as UL, FCC, CE, CB, UN, RoHS, and REACH. The company possesses over 30 patents and has significant experience in the renewable energy industry.

TCSN's products are highly reliable, designed for high charge/discharge rates, and take into account both quality and cost-effectiveness. They have received positive feedback from both domestic and international markets.
